About SIEMENS ET 200SP, AI 8XI 2-4-Wire Basic 6ES7134-6GF00-0AA1

 Manufacturer SeriesS7 ET 200 CPU BRAND SIEMENS Product type designation AI 8xI 2-/4-wire BSTEP 7 TIA Portal configurable/integrated from versionV13 SP1MODEL NAME/NUMBER6ES7134-6GF00-0AA1SIMATIC ET 200SP, Analog input module, AI 8XI 2-/4-wire Basic, suitable for BU type A0, A1, Color code CC01, Module diagnostics, 16 bit

Siemens SIMATIC ET 200SP

Analog Input Module: AI 8xI 2-/4-wire Basic

Article No: 6ES7134-6GF00-0AA1
HW Status: FS21
Firmware Version: V1.0.1 (FW update possible)
Base Units Supported: A0, A1
Color Code: CC01

General Information

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: No

• Measuring Range Scalable: No

• Engineering Software:

  • STEP 7 TIA Portal V13 SP1

  • STEP 7 V5.5 SP3

• PROFIBUS GSD: Revision 3, 5+

• PROFINET GSDML: V2.3

Operating Mode

• Oversampling: No

• MSI: No

• Configuration in RUN: Not possible

• Calibration in RUN: Not possible

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 19.2 28.8 V

• Reverse polarity protection: Yes

• Current consumption (max): 25 mA (without sensor supply)

Encoder Supply

• 24 V encoder supply: Yes

• Short-circuit protection: Yes

• Max output current: 0.7 A (total for all channels)

Power Loss

• Typical: 0.7 W (without encoder supply)

Address Area

• Max address space per module: 16 bytes

Hardware Configuration

• Automatic Encoding: Yes

• Mechanical coding element: Type A

• BaseUnit selection for connection:

  • 1-, 2-, or 4-wire: BU type A0, A1 (+ potential distributor for 4-wire)

Analog Inputs

• Number of inputs: 8 (single-ended)

• Current measurement: 8 channels

• Permissible input current: max. 50 mA

• Cycle time (all channels): min. 1 ms per channel

Input Ranges & Resistance:

• Shielded cable max length: 200 m

• Integration time: parameterizable

• Conversion time per channel: 180 / 60 / 50 / 0.625 ms (depends on frequency)

• Smoothing levels: 4 (None, Low, Medium, High)

Encoder Connection

• Voltage measurement: No

• Current measurement: 2-wire & 4-wire transducers

• Max burden (2-wire): 650

Errors & Accuracies

• Linearity error: 0.01 %

• Temperature error: 0.005 %/K

• Crosstalk: 50 dB

• Repeat accuracy: 0.05 %

• Operational error over full temp range: 0.5 %

• Basic error (25 C): 0.3 %

Diagnostics / Status

• Functions: Yes

• Alarms: Diagnostic alarm only

• Supply voltage monitoring: Yes

• Wire-break, short-circuit, group error, overflow/underflow: Yes

• LED indicators: PWR (green), Channel status (green), DIAG (green/red)

Potential Separation & Isolation

• Between channels: No

• Channels Backplane bus: Yes

• Channels Power supply: No

• Isolation test: 707 V DC

Ambient Conditions

• Operation Temp: -30 to 60 C horizontal, -30 to 50 C vertical

• Storage/Transport: See manual

• Altitude max: 5,000 m

Dimensions & Weight

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 31 g
