SIEMENS ET 200SP, AQ 2 X UI High Speed 6ES7135-6HB00-0CA1

About SIEMENS ET 200SP, AQ 2 X UI High Speed 6ES7135-6HB00-0CA1

Manufacturer SeriesS7 ET 200 CPUBRANDSIEMENSProduct type designationAQ 2xU/I HFSTEP 7 TIA Portal configurable/integrated from versionV13 / V13MODEL NAME/NUMBER6ES7135-6HB00-0CA1SIMATIC ET 200SP, Analog output module, AQ 2x U/I High Feature suitable for BU type A0, A1, Color code CC00, channel diagnostics, 16 bit, +/-0.1%

General Information:

• Product type designation: AQ 2xU/I HF

• HW functional status: FS21

• Firmware version: V1.0.3 (FW update possible)

• Usable BaseUnits: BU type A0, A1

• Color code: CC00

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes

Engineering / Configuration:

• STEP 7 TIA Portal: from V13

• STEP 7: from V5.5 SP3

• PCS 7: from V8.1 SP1

• PROFIBUS GSD Revision: 5

• PROFINET GSDML: V2.3

Operating Mode:

• Oversampling: No

• MSO: No

• Reparameterization in RUN: No

• Calibration in RUN: No

Supply Voltage:

• Rated: 24 V DC

• Permissible range: 19.2 28.8 V

• Reverse polarity protection: Yes

Input Current:

• Typical: 45 mA (without load)

• Max: 90 mA (2 channels, 20 mA)

Power Loss:

• Typical: 0.9 W

Address Area:

• Max address space per module: 4 byte + 1 byte QI information

Hardware Configuration:

• Automatic encoding: Yes

• Mechanical coding element: Type A

Analog Outputs:

• Number of outputs: 2

• Voltage output short-circuit protection: Yes

• Max short-circuit current: 45 mA

• Cycle time (all channels): min. 750 s

Output Ranges:

• Voltage: 010 V (15 bit), 15 V (13 bit), -5+5 V (15 bit), -10+10 V (16 bit)

• Current: 020 mA (15 bit), -20+20 mA (16 bit), 420 mA (14 bit)

Actuator Connections:

• Voltage output: 2-wire / 4-wire

• Current output: 2-wire

• Load impedance: Voltage 2 k, max capacitive 1 F; Current max 500 , max inductive 1 mH

• Max cable length: shielded 1000 m; voltage output 200 m

Accuracy / Errors:

• Output ripple: 0.02%

• Linearity error: 0.03%

• Temperature error: 0.003%/K

• Crosstalk: max -50 dB

• Repeat accuracy: 0.03%

• Operational error (overall temperature): 0.2%

• Basic error (25 C): 0.1%

Isochronous Mode:

• Execution/activation time (TCO): min. 500 s

• Bus cycle time (TDP): min. 750 s

• Jitter: max 5 s

Diagnostics / Status:

• Diagnostics function: Yes

• Substitute values: Connectable

• Diagnostic alarm: Yes

• Monitored: Supply voltage, wire-break (current), short-circuit (voltage), group error, overflow/underflow

• LED indication: PWR green, Channel status green, Channel diagnostics red, Module diagnostics green/red

Potential Separation / Isolation:

• Between channels: No

• Between channels and backplane bus: Yes

• Between channels and power supply: Yes

• Isolation tested: 707 V DC

Ambient Conditions:

• Horizontal installation: -30 C to 60 C (<0 C from FS04)

• Vertical installation: -30 C to 50 C (<0 C from FS04)

• Max installation altitude: 5000 m

Dimensions:

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 31 g
