About SIEMENS G120C AC DRIVE-6SL3210-1KE13-2UB2

The SIEMENS G120C AC DRIVE-6SL3210-1KE13-2UB2 is a high-quality industrial AC drive with a frequency range of 47-63 Hertz (HZ) and dimensions of 173X73X155 millimeters (mm). It operates at a rated voltage of 380-480 Volt (V) and features a digital display for easy monitoring. Designed for industrial applications, this AC drive comes with a V/F control system and offers IP20 protection. With a one-year warranty, this AC drive is a reliable and efficient solution for various industrial needs.

SINAMICS G120C

Article No.: 6SL3210-1KE13-2UB2

Rated Data

Input:

• Phases: 3 AC

• Line Voltage: 380 480 V (+10% / -20%)

• Line Frequency: 47 63 Hz

• Rated Current (LO): 4.10 A

• Rated Current (HO): 3.20 A

Output:

• Phases: 3 AC

• Rated Voltage: 400 V IEC / 480 V NEC

• Rated Power (LO): 1.10 kW / 1.50 hp

• Rated Power (HO): 0.75 kW / 1.00 hp

• Rated Current (LO): 3.10 A

• Rated Current (HO): 2.20 A

• Rated Current (IN): 3.20 A

• Max Output Current: 4.40 A

• Pulse Frequency: 4 kHz

• Output Frequency (Vector Control): 0 240 Hz

• Output Frequency (V/f Control): 0 550 Hz

Overload Capability

• Low Overload (LO): 150% base load current for 3 s, then 110% for 57 s (300 s cycle)

• High Overload (HO): 200% base load current for 3 s, then 150% for 57 s (300 s cycle)

General Specifications

• Power Factor : 0.70 0.85

• Offset Factor cos : 0.95

• Efficiency : 0.97

• Sound Pressure Level (1 m): 49 dB

• Power Loss: 48.1 W

• Filter Class: Unfiltered

Communication

• USS / MODBUS RTU

Inputs / Outputs

• Standard Digital Inputs: 6 (01: 11 V, 10: 5 V, max inrush 15 mA)

• Fail-safe Digital Inputs: 1

• Digital Outputs:

  • Relay: 1 (DC 30 V, 0.5 A)

  • Transistor: 1 (DC 30 V, 0.5 A)

• Analog / Digital Inputs: 1 (Differential, 10-bit, switching threshold 01: 4 V, 10: 1.6 V)

• Analog Outputs: 1 (Non-isolated)

• Motor Temp Sensor: 1 (PTC/KTY/Thermo-Click, 5 C)

Closed-loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with Flux Current Control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless Vector Control: Yes

• Vector Control with Sensor: No

• Encoderless Torque Control: No

• Torque Control with Encoder: No

Ambient Conditions

• Cooling: Air cooling using integrated fan (0.005 m/s)

• Installation Altitude: 1,000 m

• Operation Temperature: -10 40 C

• Transport Temperature: -40 70 C

• Storage Temperature: -25 55 C

• Max Relative Humidity: 95% (no condensation or icing)

Connections

• Signal Cable: 0.15 1.50 mm (AWG 24 16)

• Line Side / Motor End / DC Link: Plug-in screw terminals, 1.00 2.50 mm (AWG 18 14)

• Max Line Length: 15 m

• PE Connection: On housing with M4 screw

• Max Motor Cable Length: Shielded / Unshielded 150 m

Mechanical Data

• Degree of Protection: IP20 / UL open type

• Frame Size: FSAA

• Net Weight: 1.40 kg

• Dimensions (W H D): 73 173 155 mm
