About SIEMENS VFD G120XA 6SL3225-2YD62-0CB0

SINAMICS G120XA Rated power 450kW 3AC 380V -20% to 440V +10% Integrated class A C3 filter 110% 60s per 600s with integrated BOP-2 Integrated Fieldbus: MODBUS RTU, BACnet MS/TP, USS 6DI, 4DQ, 2AI, 2AQ, 1Mot_t Protection: IP00 Frame Size: FSJ 1438x801x410 (HxWxD)

SINAMICS G120XA

Article No.: 6SL3225-2YD62-0CB0
High-Power AC Drive 3-phase input/output

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380440 V (+10% / 15%)

• Line frequency: 4763 Hz

• Rated current (LO): 870 A

Output

• Phases: 3 AC

• Rated voltage: 400 V

• Rated power (LO): 450 kW (IEC 400 V)

• Rated current:

  • 400V: 803.04 A

  • 380V: 840.00 A

  • LO: 784 A

• Max. output current: 1,107 A

• Pulse frequency: 2 kHz

• Output frequency: 0100 Hz (Vector & V/f control)

Overload Capability

• Low Overload (LO): 110% base load current for 60 s in a 600 s cycle

General Technical Specifications

• Power factor : 0.750.93

• Power factor cos : 0.99

• Efficiency : 0.98

• Sound pressure level (1 m): 75.4 dB

• Power loss (typical): 9.55 kW

• Filter class: Integrated RFI filter (Category C3)

• EMC category: Category C3 (with accessories)

• Safety function: "Safe Torque Off" without SIRIUS device (via S7-1500F)

Communication

• USS, Modbus RTU, BACnet MS/TP

Inputs / Outputs

• Standard digital inputs: 6

  • Switching levels: 0 1 = 11 V, 1 0 = 5 V

  • Max inrush current: 15 mA

• Fail-safe digital inputs: 0

• Digital outputs (relay): 4 (DC 30 V, 1 A)

• Transistor outputs: 0

• Analog/differential inputs: 2 (12-bit resolution)

  • Switching threshold: 0 1 = 4 V, 1 0 = 1.6 V

• Analog outputs: 2 (non-isolated)

• PTC/KTY interface: 1 motor temperature sensor input (PTC, KTY, PT1000, Thermo-Click), 5 C accuracy

Closed-Loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with flux current control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: Yes

• Torque control with encoder: No

Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling with integrated fan

• Cooling air requirement: 0.345 m/s

• Installation altitude: 1,000 m

• Ambient temperature:

  • Operation: 060 C

  • Transport: 4070 C

  • Storage: 2555 C

• Relative humidity: Max 95% at 40 C, no condensation or icing

Connections

• Signal cable: 0.151.50 mm

• Line side: M12 screw, 4 240 mm

• Motor end: M12 screw, 4 240 mm

• DC link (braking resistor) / PE: M12 screw

• Max. motor cable length: Shielded 100 m

Mechanical Data

• Degree of protection: IP00

• Frame size: FSJ

• Net weight: 204 kg

• Dimensions (W H D): 801 1,438 410 mm
