SIEMENS SIMATIC S7-1200, Digital output SM 1222, 6ES7222 1XF32 0XB0

The SIMATIC S7-1200 is a versatile industrial automation solution that includes the Digital output SM 1222 module with the part number 6ES7222 1XF32 0XB0. Built for DIN Rail mounting, this standard-sized module is designed to deliver high-quality performance in industrial settings. Its grey color and digital output type make it suitable for various applications requiring precise control. With a frequency of 50/60 Hertz (HZ), this module is ideal for automation systems that demand reliability and accuracy. As an exporter, manufacturer, supplier, and trader, this product provides a seamless integration for your automation needs.

SIMATIC S7-1200 SM 1222 Digital Output Module

Article No.: 6ES7222-1XF32-0XB0
Type: SM 1222, 8 DO, Relay Changeover Contact
Output Type: Relay, 2 A

General Information

• Number of Digital Outputs: 8 (groups of 1)

• Output Type: Relay changeover contact

• Short-Circuit Protection: Not included (to be provided externally)

• Power Loss: 5 W (typical)

Supply Voltage & Input Current

• Permissible DC Range: 20.4 28.8 V

• Backplane Bus Current: max. 140 mA

• Load Voltage Current: max. 16.7 mA per relay coil

Output Specifications

• Switching Capacity:

  • Resistive load: max. 2 A

  • Lamp load: max. 30 W DC / 200 W AC

  • Inductive load: max. 2 A

• Rated Output Voltage:

  • DC: 5 30 V

  • AC: 5 250 V

• Rated Output Current: 2 A per channel

• Output Delay (Resistive Load):

  • 0 1: max. 10 ms

  • 1 0: max. 10 ms

• Total Current per Group (horizontal, up to 50C): max. 2 A

Relay Output Details

• Number of Relay Outputs: 8

• Rated Supply Voltage of Coil: 24 V DC

• Mechanical Operating Cycles: max. 10 million

• Electrical Operating Cycles: max. 100,000 at rated load

Cabling

• Max Cable Length:

  • Shielded: 500 m

  • Unshielded: 150 m

Diagnostics & Status

• Diagnostic Alarm: Yes

• LED Status Indicators: Yes (for output status)

Potential Separation

• Between Channels: Relays

• Between Channels and Backplane Bus: 1,500 V AC for 1 min

• Between Circuits: 750 V AC for 1 min

Environmental & Protection

• IP Rating: IP20

• Ambient Temp (Operation):

  • Horizontal: -20C to 60C

  • Vertical: -20C to 50C

  • Max 8 outputs at 55C horizontal / 45C vertical

• Storage Temp: -40C to 70C

• Relative Humidity: up to 95% (non-condensing)

• Air Pressure (Storage/Transport): 660 1080 hPa

• Free Fall: max. 0.3 m (5 times in packaging)

Mechanical Data

• Front Connector: Required

• Material: Plastic

• Dimensions: W 70 mm H 100 mm D 75 mm

• Weight: 310 g
