About SIMATIC S7-1200F, CPU 1215 FC, compact CPU, DCDCDC

Siemens SIMATIC S7-1200F CPU 1214 FC

A compact and fault-tolerant PLC designed for reliable industrial automation. The CPU 1214 FC (DC/DC/DC) delivers secure operation for medium-sized automation tasks where system safety and fault tolerance are essential.

Key Features

• Compact design suitable for small or space-limited control panels

• Fault-tolerant (F-class) controller for mission-critical applications

• DC/DC/DC output for powering various industrial devices

• High processing speed for efficient automation performance

• Multiple communication ports for easy system integration

• Built-in diagnostics for quick fault detection and monitoring

• Expandable with compatible I/O and communication modules

• Fully supported in TIA Portal for programming and maintenance

About Naksh Technology

Naksh Technology provides genuine Siemens SIMATIC S7-1200F CPU 1214 FC controllers with complete technical support to help you achieve reliable and optimized automation performance.

SIMATIC S7-1200F CPU 1215FC (DC/DC/DC)

Article No.: 6ES7215-1AF40-0XB0
Firmware version: V4.7
Programming: STEP 7 V20 or higher

General Information

• Compact CPU with onboard I/O:

  • 14 DI 24 V DC

  • 10 DO 24 V DC, 0.5 A

  • 2 AI 010 V DC

  • 2 AO 020 mA DC

• Power supply: DC 20.428.8 V

• Program/Data memory: 250 KB / 4 MB

• Backup: Maintenance-free, without battery

CPU Performance

• Processing times:

  • Bit operations: 0.08 s

  • Word operations: 1.7 s

  • Floating point: 2.3 s

• Counters: 6, max. 100 kHz

• PID controller: Yes

• Positioning axes: 8 (pulse-direction interface: 4)

Digital Inputs

• Number: 14 (6 for high-speed counting)

• Input voltage: 24 V DC

• Simultaneously controllable inputs: max. 14

• Input delay: 0.05 s 20 ms (parameterizable)

• Cable length:

  • Shielded: max. 500 m

  • Unshielded: max. 300 m

Digital Outputs

• Number: 10 (4 high-speed pulse train outputs)

• Output voltage: 024 V DC

• Output current: max. 0.5 A

• Switching frequency: up to 100 kHz

Analog Inputs/Outputs

• Analog inputs: 2, 010 V, input resistance 100 k

• Analog outputs: 2, 020 mA

• Conversion time per channel: 625 s

• Resolution: 10 bit

Communication

• Interfaces: 2 PROFINET ports, RJ45, integrated switch

• Protocols: PROFINET IO Controller/Device, PROFIsafe, PROFIBUS (via CM 124x), OPC UA, MODBUS

• Web server: Supported

• Media redundancy: MRP supported

Diagnostics & Status

• LEDs: RUN/STOP, ERROR, MAINT

• Diagnostic buffer: Yes

• Traces: 2 configurable, max. 512 kB each

• Forcing: Supported

Safety / Fail-Safe

• Highest safety class:

  • Performance Level (ISO 13849-1): PLe

  • SIL (IEC 61508): SIL 3

Potential Separation

• Digital inputs: Not separated

• Digital outputs: Separated in groups of 1

EMC / Interference Immunity

• ESD: 8 kV air, 6 kV contact

• Supply/Signal lines: IEC 61000-4-4, 4-5, 4-6 compliant

• Radio interference: EN 55011, Class A/B

Ambient Conditions

• Operation temperature: 0 55 C (horizontal), 0 45 C (vertical)

• Storage temperature: -40 70 C

• Relative humidity: max. 95 %, no condensation

• Vibration / Shock: IEC 60068-2-6, 2 g; IEC 60068-2-27, 15 g / 11 ms

• Altitude: -1,000 5,000 m

Mechanical Data

• Dimensions: W 130 H 100 D 75 mm

• Weight: ~500 g

• Protection class: IP20
