About SIEMENS 6ED1052-1CC08 0BA1

The 6ED1052-1CC08 0BA1 is a reliable industrial rack-mounted device designed for various applications. With a durable grey color and standard size measuring 71.5 x 90 x 60 mm, this product ensures high performance and longevity in industrial settings. Its 12-millimeter thickness and robust build make it suitable for heavy-duty use. As an exporter, manufacturer, supplier, and trader, we guarantee top-quality and service for up to 12 months with this innovative product.

Data Sheet 6ED1052-1CC08-0BA1

LOGO! 24CE Logic Module (Spare Part)

• Display / Power Supply / I/O: 24 V / 24 V / 24 V transistor

• 8 DI (4 AI) / 4 DQ

• Memory: 400 blocks, modularly expandable

• Ethernet, integrated web server, data logging, user-defined web pages

• Standard microSD card for LOGO! Soft Comfort V8.3 or higher

• Cloud connection available in all LOGO! 8.3 basic units

Display

• With display: Yes

Installation / Mounting

• Mounting: 35 mm DIN rail

• Width: 4 spacing units

Supply Voltage

• Rated value DC: 24 V DC

• Permissible range: 20.4 28.8 V DC

Time of Day / Time Switching

• Number of clocks: 400 (max., function-specific)

• Power reserve: 480 h

Digital Inputs

• Number: 8 (4 can be used in analog mode, 010 V)

Digital Outputs

• Number: 4 (Transistor)

• Short-circuit protection: Yes, electrical (1 A)

• Output current (signal "1"): max. 0.3 A at 055 C

EMC

• Emission of radio interference: EN 55011, Class B

• For use in residential areas: Yes

Standards / Approvals

• CE mark: Yes

• CSA approval: Yes

• UL approval: Yes

• FM approval: Yes

• Developed in accordance with IEC 61131

• According to VDE 0631

• Marine approval: Yes

Ambient Conditions

• Operation temperature: -20 C 55 C (No condensation)

• Storage / transport temperature: -40 C 70 C

• Installation altitude: -1000 m +2000 m (1 080 795 hPa)

Dimensions

• Width: 71.5 mm

• Height: 90 mm

• Depth: 60 mm

Technical Details
