SIEMENS CPU1515SP PC2 (Windows 10 OS) + 2048PT 6ES7677-2DB42-0GM0

The SIEMENS CPU1515SP PC2 (Windows 10 OS) + 2048PT 6ES7677-2DB42-0GM0 is a compact and reliable automation solution designed for industrial applications. With dimensions of 160 x 117 x 75 mm, this lightweight unit (0.83 kg) ensures space-efficient installation on DIN-rail mounts. The CPU operates on 24V DC power, with an input current of 2.9A and a power rating of 43W. Featuring an IP20 protection level, it is built to withstand humid environments with up to 95% relative humidity and supports a broad operating temperature range of -20C to +60C. Equipped with Windows 10 OS, the CPU delivers high-performance computational capabilities for automation tasks. Its robust grey housing ensures durability, while its frequency compatibility of 50/60 Hz makes it adaptable to various electrical systems. This module provides seamless integration into automation setups while maintaining efficiency and reliability.

Basic Description

SIMATIC ET 200SP Open Controller (CPU 1515SP PC2 + HMI 2048PT)
8 GB RAM
128 GB CFast (Windows 10 IoT Enterprise LTSC 2019 64-bit)
S7-1500 Software Controller CPU 1505SP V2x
WinCC Runtime Advanced V17 (2048 PowerTags)
Interfaces:
1 CFast slot, 1 SD/MMC slot, ET 200SP BusAdapter (PROFINET),
1 Ethernet (10/100/1000 Mbps), 2 USB 3.0, 2 USB 2.0, 1 DisplayPort

General Information

• Product type: CPU 1515SP PC2

• HW functional status: FS04

• Firmware version: V20.8

• TIA Portal: from V16

Installed Software

• WinCC Runtime Advanced V16

• S7-1500 Software Controller CPU 1505SP

Power & Current

• Supply voltage: 24 V DC (19.228.8 V)

• Current consumption:

  • Typical: 0.5 A

  • Rated: 1.8 A

  • Max: 2.9 A

• Active power input: 43 W

• Power loss: 16 W

• Mains buffering: 5 ms

Processor & Memory

• CPU: Intel Atom E3940, 1.6 GHz, 4 cores

• Main memory: 8 GB DDR3L RAM

• CFast: 128 GB

• Load memory: 320 MB

• Work memory: 1 MB (program), 5 MB (data)

• Retentive memory: 410 kB (NVRAM), 5.2 MB (mass storage)

Block Limits

• Total elements: 6000

• DBs: max 5999, size max 5 MB

• FBs/FCs: max 5998/5999, size 1024 KB

• OBs: max 1024 KB, multiple OB types supported

I/O & Addressing

• Max IO modules: 8192

• Inputs: 32 kB

• Outputs: 32 kB

• Subprocess images: 32 max

Communication Interfaces

PROFINET Interface (via BusAdapter)

• Ports: 2 RJ45

• Speed: 10/100 Mbps

• Connections: 88

• IRT, PROFIenergy, MRP/MRPD supported

Ethernet Interface

• 1 RJ45 (1 Gbps)

PROFIBUS Interface (via CM DP)

• DP master/device

• Max DP devices: 125

Other Interfaces

• USB: 4 (2 USB2.0, 2 USB3.0)

• SD card slot: 1

• DisplayPort: 1

Protocols Supported

• PROFINET IO Controller & Device

• OPC UA (with license)

• MODBUS TCP

• TCP/IP, UDP, ISO-on-TCP

• Web server (HTTP/HTTPS)

Technology & Control

• Motion Control supported

• Up to 2400 MC resources

• PID Compact, PID 3-Step, PID Temp

• High-speed counter

Diagnostics & Commissioning

• Diagnostic buffer: 1000 entries

• Traces: 4, 512 KB each

• Forcing, breakpoints, team engineering supported

Environmental Conditions

• Operating temperature: 20 C to +60 C

• Storage: 40 C to +70 C

• Vibration & shock tested (IEC 60068)

Dimensions & Weight

• Width: 160 mm

• Height: 117 mm

• Depth: 75 mm

• Weight: 0.83 kg
