SIEMENS ET 200SP, AQ 2 X UI High Speed 6ES7135-6HB00-0DA1

About SIEMENS ET 200SP, AQ 2 X UI High Speed 6ES7135-6HB00-0DA1

Manufacturer SeriesS7 ET 200 CPU BRAND SIEMENS Product type desig nation AQ 2xU/I HSS TEP 7 TIA Portal configurable/integrated from versionV13 SP1MODEL NAME/NUMBER6ES7135-6HB00-0DA1SIMATIC ET 200SP, Analog output module, AQ 2x U/I High Speed, suitable for BU type A0, A1, Color code CC00, channel diagnostics, 16 bit, +/-0.2%

Data Sheet 6ES7135-6HB00-0CA1

• SIMATIC ET 200SP Analog Output Module, AQ 2x U/I High Feature
• Suitable for BU type A0, A1 Color code CC00 Channel diagnostics 16-bit 0.1%

General Information

• Product type designation: AQ 2xU/I HF

• HW functional status: from FS21

• Firmware version: V1.0.3

• FW update possible: Yes

• Usable BaseUnits: BU type A0, A1

• Color code: CC00

Product Function

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes

Engineering With

• STEP 7 TIA Portal: from V13

• STEP 7: from V5.5 SP3

• PCS 7: from V8.1 SP1

• PROFIBUS GSD: Revision 5

• PROFINET GSDML: V2.3

Operating Mode

• Oversampling: No

• MSO: No

• CiR: Repara meterization in RUN: No

• Calibration in RUN: No

Supply Voltage

• Rated value: 24 V DC

• Range: 19.2 V 28.8 V DC

• Reverse polarity protection: Yes

Input Current

• Current consumption (rated): 45 mA (without load)

• Max current consumption: 90 mA (2x 20 mA outputs)

Power Loss

• Typical power loss: 0.9 W

Address Area

• Max address space per module: 4 bytes + 1 byte QI information

Hardware Configuration

• Automatic encoding: Yes

• Mechanical coding: Yes (Type A)

Analog Outputs

• Number of outputs: 2

• Short-circuit protection (voltage output): Yes

• Max short-circuit current: 45 mA

• Minimum cycle time: 750 s

Output Voltage Ranges

• 010 V (15 bit)

• 15 V (13 bit)

• 5 to +5 V (15 bit incl. sign)

• 10 to +10 V (16 bit incl. sign)

Output Current Ranges

• 020 mA (15 bit)

• 20 to +20 mA (16 bit incl. sign)

• 420 mA (14 bit)

Actuator Connection

• Voltage output: Two-wire / Four-wire

• Current output: Two-wire

Load Impedance

• Voltage output: 2 k, capacitive max 1 F

• Current output: 500 , inductive max 1 mH

Destruction Limits

• Max voltage at outputs: 30 V

Cable Length

• Shielded: 1000 m

• Voltage output: max 200 m

Analog Value Generation

• Max resolution: 16-bit (with sign)

• Settling time: 0.05 ms for resistive, capacitive, and inductive loads

Errors / Accuracy

• Output ripple: 0.02%

• Linearity error: 0.03%

• Temperature error: 0.003%/K

• Crosstalk: 50 dB

• Repeat accuracy: 0.03%

• Operational error (temperature range):

  • Voltage: 0.2%

  • Current: 0.2%

• Basic error limit (25C):

  • Voltage: 0.1%

  • Current: 0.1%

Isochronous Mode

• Execution time (TCO): 500 s

• Bus cycle time (TDP): 750 s

• Max jitter: 5 s

Diagnostics / Alarms

• Diagnostics: Yes

• Substitute values: Yes

• Diagnostic alarm: Yes

Diagnostic Functions

• Monitoring supply voltage: Yes

• Wire-break: Yes (per channel, current mode)

• Short-circuit: Yes (per channel, voltage mode)

• Group error: Yes

• Overflow / underflow: Yes

LED Indication

• PWR LED: Green

• Channel status: Green

• Channel diagnostics: Red

• Module diagnostics: Green/Red DIAG LED

Potential Separation

• Between channels: No

• Channels Backplane bus: Yes

• Channels Electronics supply: Yes

Isolation

• Tested with 707 V DC

Ambient Conditions

• Operating temperature:

  • Horizontal: 30C to 60C

  • Vertical: 30C to 50C

• Max altitude: 5000 m

Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

Weight

• Approx.: 31 g
