SIEMENS ET 200SP, DI 8x 24V DC Basic, PU 1 6ES7131-6BF01-0AA0

About SIEMENS ET 200SP, DI 8x 24V DC Basic, PU 1 6ES7131-6BF01-0AA0

SIMATIC ET 200SP, Digital input module, DI 8x 24V DC Basic, type 2 (IEC 61131), sink input, (PNP, P-reading), Packing unit: 1 piece, fits to BU-type A0, Colour Code CC01, input delay time 0,05..20ms, module diagnostics for: supply voltage

Data Sheet: 6ES7131-6BF01-0AA0

SIMATIC ET 200SP Digital Input Module (DI 8x 24V DC Basic, Type 2, Sink Input PNP)

Packing unit: 1 piece | Fits to BU-type A0 | Colour Code: CC01
Input delay: 0.0520 ms | Module diagnostics for supply voltage

General Information

• Product type designation: DI 8x24VDC BA

• HW functional status: FS03

• Firmware version: V0.0

• FW update possible: No

• Usable BaseUnits: BU type A0

• Color code: CC01

Product Function

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: No

• Suitable for PROFINET R1 IMs: Yes

Engineering With

• STEP 7 TIA Portal: from V14

• STEP 7: from V5.5 SP3

• PROFIBUS: GSD Revision 3 and 5+

• PROFINET: GSDML V2.3

Operating Mode

• DI: Yes

• Counter: No

• Oversampling: No

• MSI: No

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 19.2 28.8 V DC

• Reverse polarity protection: Yes

Input Current

• Max consumption: 70 mA (all channels from encoder supply)

Encoder Supply

• Number of outputs: 8

• Output voltage min.: 19.2 V

• Short-circuit protection: Yes (per module)

• Output current per channel: 700 mA

• Output current per module: 700 mA

Power Loss

• Typical: 1.6 W (at 24 V, 8 inputs)

Address Area

• Inputs: 1 byte

Hardware Configuration

• Automatic encoding: Yes

• Mechanical coding element: Yes (Type A)

• Supported BaseUnits:

  • 1-wire: A0

  • 2-wire: A0

  • 3-wire: A0 with AUX

  • 4-wire: A0 + potential distributor module

Digital Inputs

• Number of inputs: 8

• Parameterizable: Yes

• Type: P-reading (sink input PNP)

• IEC 61131 types: 1 / 2 / 3

Input Voltage

• Rated: 24 V DC

• Signal 0: 30 to +5 V

• Signal 1: +11 to +30 V

Input Current

• Signal 1 typical: 6.8 mA

Input Delay (parameterizable)

• Options: 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms

• Additional delay: 30500 s (line dependent)

• Min/max 01: 0.0520 ms

• Min/max 10: 0.0520 ms

Cable Length

• Shielded: max. 1000 m

• Unshielded: max. 600 m

Encoder

• 2-wire sensors: Yes

• Max quiescent current: 2 mA

Diagnostics

• Diagnostics function: Yes

• Diagnostic alarm: Yes

• Diagnostic info readable: Yes

• Supply voltage monitoring: Yes (parameterizable)

• Group error: Yes

LEDs

• PWR (supply): Green

• Channel status: Green

• Module diagnostics: Green/Red DIAG

• Channel diagnostic LED: No

Potential Separation

• Between channels: No

• Channels backplane bus: Yes

• Channels electronics power supply: No

Isolation

• Tested with: 707 V DC

Environmental Data

• Suitable for safety functions: No

• Environmental product declaration: Yes

Global Warming Potential (CO eq)

• Total: 15.9 kg

• Production: 3.69 kg

• Operation: 12.7 kg

• End of life: 0.495 kg

Ambient Conditions

• Operating temperature (horizontal): 30 to 60C

• Operating temperature (vertical): 30 to 50C

• Max installation altitude: 5000 m (restrictions >2000 m)

Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

Weight

• Approx.: 28 g
