SIEMENS ET 200SP, DQ 4x24..230VAC2A HF (Model: 6ES7132-6FD00-0CU0)

The SIEMENS ET 200SP DQ 4x24..230VAC2A HF is a compact and reliable automation module designed for industrial applications.

Key Specifications:

• Rated Voltage: 230 V

• Output Voltage: 24 V AC to 230 V AC

• Frequency: 4763 Hz

• Operating Temperature: -30C to +60C

• Humidity Tolerance: Up to 95%

• Protection Level: IP20

• Dimensions (L W H): 20 73 58 mm

• Weight: 50 g

• Mounting: DIN rail

• Power Loss: 9 W

• Output Current: 10 mA

Features:

• Compact and lightweight for space-saving installation

• DIN-rail mounting for easy integration

• IP20 protection ensures safety in controlled environments

• Operates efficiently in varied industrial conditions

• High-performance module designed for precision-driven automation systems

Ideal for cost-effective and reliable automation solutions in industrial setups.

Data Sheet 6ES7132-6FD00-0CU0

SIMATIC ET 200SP Digital Output Module DQ 4 24230 V AC / 2 A HF

General Information

• Product type: DQ 4 24230 V AC / 2 A HF

• Hardware version: From FS03

• Firmware update: Possible

• BaseUnit type: U0

• Color code: CC20

• Supports I&M0I&M3

Configuration / Engineering

• TIA Portal: Supported from V14

• STEP 7 Classic: Supported from V5.5

• PROFIBUS: GSD Revision 5 or higher

• PROFINET: GSDML V2.3

Operating Modes

• DQ mode: Yes

• Energy-saving mode: Yes

• PWM: No

• Oversampling: No

• Phase control: Yes (8.5 100% angle)

• Half-wave: Yes

• Full-wave: Yes

Supply Voltage

• Rated voltage: 230 V AC (4763 Hz)

• Max frequency change rate: 1 mHz/s

• Permissible range:

  • Lower limit: 20.4 V AC

  • Upper limit: 264 V AC

• Current consumption (no load): 8 mA

Power Loss

• Typical: 9 W
  (At 230 V AC, all outputs at 2 A, 50 Hz)

Address Area

• Inputs: +1 byte (QI)

• Outputs: 8 bytes

Hardware Features

• Automatic encoding: Yes

• Mechanical coding: Yes (Type C)

• Compatible BaseUnits: U0 (1-wire, 2-wire, 3-wire with potential distributor)

Digital Outputs

• Output type: Triac

• Total outputs: 4

• Current-sourcing: Yes

• Parameterizable: Yes

Protection

• Short-circuit protection: No (external fuse required)

• Open-circuit detection: Yes (per channel)

  • Threshold: 1 mA @ 40 V AC

• Overload protection: No

  • Must use 10 A fast-acting fuse

Switching Capacity

• Resistive load: 2 A max (4 A max, see manual)

• Inductive load: 2 A

• Lamp load: 100 W max

Output Voltage

• Signal 1: 20.4 V AC

Output Current

• Rated: 2 A

• Range: 10 mA 4 A (check derating)

• Residual current (0): 3 mA

Switching Times

• 0 1: 40 ms

• 1 0: 20 ms

Parallel Operation

• Logic links: No

• Uprating: No

• Redundant control: Yes

Switching Frequency (DQ mode)

• Resistive load: 10 Hz

• Inductive load (AC15): 10 Hz

• Lamp load: 1 Hz
  (PC mode limited by line frequency)

Total Current

• Per channel: 2 A max (4 A max, see manual)

• Per module: 8 A max

Thermal Limits

Horizontal installation

• Up to 40C: 8 A

• Up to 50C: 6 A

• Up to 60C: 4 A

Vertical installation

• Up to 30C: 8 A

• Up to 40C: 6 A

• Up to 50C: 4 A

Cable Length

• Shielded: 1000 m

• Unshielded: 600 m

Diagnostics & Status

• Diagnostics: Yes

• Substitute values: Yes

• Diagnostic alarm: Yes

• Supply monitoring: Yes

• Wire-break: Yes

• Short-circuit: No

• Group error: Yes

LED Indicators

• Power (PWR): Green

• Channel status: Green

• Channel diagnostics: Red (Fn)

• Module diagnostics: Green/Red (DIAG)

Isolation

• Channels to backplane bus: Yes

• Channels to electronics supply: No

• Channel-to-channel isolation: No

• Tested with: 2545 V DC for 2 s

Ambient Conditions

Operating Temperature

• Horizontal: 30C to +60C

• Vertical: 30C to +50C

Altitude

• Max: 2000 m
  (Higher on request)

Mechanical Data

• Width: 20 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 50 g
