SIMATIC S7-1500F, CPU 1513F 1 PN

The SIMATIC S7-1500F, CPU 1513F 1 PN (Model: 6ES7513-1FM03-0AB0) is a high-performance automation processor engineered to meet demanding industrial applications. Designed for reliability and efficiency, it operates within a temperature range of -30C to +60C, making it suitable for extreme environments. With DIN-rail mounting, it is easy to install and integrates seamlessly into your automation system. This black-colored unit weighs just 336 grams and is compact with dimensions of 35 x 147 x 129 mm, ensuring it fits even in space-constrained setups. Powered by a 24V DC voltage, it offers a rated current of 1.15A and power output of 10W while maintaining minimal power loss of only 3.4W. The CPU features an RJ-45 Ethernet interface type, delivering robust communication capabilities. Additionally, the device is built with an IP65 protection level and can withstand up to 95% humidity, ensuring high durability and operational stability in industrial conditions. Ideal for automation, this product combines energy efficiency, rugged design, and precision performance to meet the evolving needs of modern industries.

SIMATIC S7-1500F CPU 1513F-1 PN (6ES7513-1FM03-0AB0)

General Information

• Product Type: CPU 1513F-1 PN

• HW Functional Status: FS04

• Firmware Version: V4.0 (FW update possible)

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: Yes (Distributed & Central)

• SysLog: Yes

• Engineering: STEP 7 TIA Portal V20 (FW V4.0) / V18 (FW V3.0) or higher

Display & Control

• Screen Diagonal: 3.45 cm

• Keys: 8

• Mode Buttons: 2

Power Supply

• Rated Voltage: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Reverse Polarity Protection: Yes

• Mains Buffering: 5 ms

• Current Consumption: 0.56 A (nominal), 0.9 A (max)

• Inrush Current: 1.15 A

• Power Consumption: 10 W (backplane), 5.5 W (balanced)

• Power Loss: 3.4 W

Memory

• Work Memory:

  • Program: 900 KB

  • Data: 2.5 MB

• Load Memory (SIMATIC Memory Card): Max. 32 GB

• Number of Memory Card Slots: 1

CPU Performance

• Bit Operations: 6 ns

• Word Operations: 7 ns

• Fixed Point Arithmetic: 9 ns

• Floating Point Arithmetic: 37 ns

CPU Blocks

• Total Blocks: 4,000 (OB, FB, FC, DB, UDTs)

• Data Blocks (DB): 160,999 (User: 159,999)

  • Max Size: 2.5 MB

• Function Blocks (FB) & Functions (FC): 065,535, max 900 KB each

• Organizational Blocks (OB): Max 900 KB

• Cycle OBs: 100

• Time Alarm OBs: 20

• Delay Alarm OBs: 20

• Cyclic Interrupt OBs: 20 (min OB 3x cycle 250 s)

• Process Alarm OBs: 50

Counters & Timers

• S7 Counters: 2,048 (retentive adjustable)

• IEC Counters: Any (limited by memory)

• S7 Timers: 2,048 (retentive adjustable)

• IEC Timers: Any (limited by memory)

Data Areas

• Retentive Data Area: Max 256 KB

• Extended Retentive Data Area: Max 2.5 MB

• Flag Memory: Max 16 KB

I/O Addressing

• Number of I/O Modules: 2,048

• Inputs: 32 KB

• Outputs: 32 KB

• Per Integrated IO Subsystem: 8 KB inputs / 8 KB outputs

• Number of Distributed IO Systems: 32

Interfaces

• PROFINET: 1 interface, 2-port RJ45, integrated switch

• Protocols: IPv4, PROFINET IO Controller/Device, Open IE, Web server, Media redundancy, MODBUS TCP, PROFIsafe V2.4/V2.6

• Connections: Max 128, including reserved for ES/HMI/web: 10

OPC UA

• Runtime License Required: Yes ("Small" license)

• Server: Data access, method call, alarms & conditions, role-based access

• Client Connections Max: 4

Motion Control & PID

• Available Motion Control Resources: 1,120

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

Safety

• Performance Level (ISO 13849-1): PLe

• SIL (IEC 61508): SIL 3

• PFDavg: < 2.0E-05

• PFH: < 1.0E-09

• PROFINET Security Class: 1

Ambient Conditions

• Operation (Horizontal): -30C to 60C (Display 50C)

• Operation (Vertical): -30C to 40C (Display 40C)

• Storage/Transport: -40C to 70C

• Max Installation Altitude: 5,000 m

Programming

• Languages Supported: LAD, FBD, STL, SCL, CFC, GRAPH

• Protection: User program, copy, block, write/read, failsafe

• Users / Groups / Roles: 100 / 100 / 50

Dimensions & Weight

• Width: 35 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 336 g

Certifications

• General Product Approval: KC, FM

• Functional Safety: PLe / SIL 3

• Maritime Application: NK, CCS

Technical Details
