SIEMENS ET 200SP, DQ 4x24VDC2A HF 6ES7132-6BD20-0CA0

About SIEMENS ET 200SP, DQ 4x24VDC2A HF 6ES7132-6BD20-0CA0

Manufacturer SeriesS7 ET 200 CPU BRAND SIEMENS Product type designation DQ 4x DC 24 V/2 A HFSTEP 7 TIA Portal configurable/integrated from versionV13 SP1 / -MODEL NAME/NUMBER6ES7132-6BD20-0CA0SIMATIC ET 200SP, digital output module, DQ 4x 24VDC/2A High Feature, suitable for BU type A0, Color code CC02, channel diagnostics

General Information

• Product type designation: DQ 4x DC 24 V/2 A HF

• HW functional status: FS20 or higher

• Firmware version: V2.0.3 (FW update possible)

• Usable BaseUnits: BU type A0

• Color code: CC02

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: Yes

Engineering / Configuration

• STEP 7 TIA Portal: from V13 SP1

• STEP 7: from V5.5

• PROFIBUS GSD Revision: 5

• PROFINET GSDML: V2.3

Operating Mode

• DQ: Yes

• DQ with energy-saving: No

• PWM: No

• Oversampling: No

• MSO: Yes

Supply Voltage

• Rated: 24 V DC

• Permissible range: 19.2 28.8 V

• Reverse polarity protection: Yes

• Current consumption: 28 mA (typ./max)

Output / Digital Outputs

• Type: Source output (PNP, current-sourcing)

• Number of outputs: 4

• Parameterizable: Yes

• Short-circuit protection: Electronic (response threshold 2.85.2 A)

• Output voltage: 24 V DC rated

• Load capacity: Resistive max 2 A, lamp max 10 W

• Output current per channel: 2 A max

• Output delay: "0""1" 50 s, "1""0" 100 s

• Switching frequency: Resistive max 100 Hz, inductive max 2 Hz, lamp max 10 Hz

• Total current per module: 8 A (temperature derating applies)

Cable Length

• Shielded: max 1000 m

• Unshielded: max 600 m

Isochronous Mode

• Bus cycle time (TDP) min: 500 s

• Jitter max: 8 s

Diagnostics / Status

• Diagnostics function: Yes

• Substitute values: Connectable

• Monitored: Supply voltage, Wire-break, Short-circuit to M/L+, Group error

• LED indication: PWR green, Channel status green, Channel diagnostics red, Module diagnostics green/red

Potential Separation / Isolation

• Between channels: No

• Between channels and backplane bus: Yes

• Isolation tested: 707 V DC

Standards / Safety

• Suitable for safety functions: No

• Safety-related tripping: Yes (PL d / SIL 2)

• Environmental product declaration: Yes (ISO 14021)

• Global warming potential (CO eq): Total 29.3 kg (Production 4 kg, Operation 25.6 kg, End-of-life 0.245 kg)

Ambient Conditions

• Horizontal installation: -30 C to 60 C

• Vertical installation: -30 C to 50 C

• Max installation altitude: 5000 m

Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 30 g
