SIEMENS ET 200SP, TM Timer DIDQ 10x24V 6ES7138-6CG00-0BA0

About SIEMENS ET 200SP, TM Timer DIDQ 10x24V 6ES7138-6CG00-0BA0

Manufacturer SeriesS7 ET 200 CPU BRAND SIEMENS STEP 7 TIA Portal configurable/integrated from versionV13 Update 3MODEL NAME/NUMBER6ES7138-6CG00-0BA0Product type designation TM Timer DIDQ 10x24VSIMATIC ET 200SP, TM timer DIDQ 10x 24V time-controlled digital inputs and outputs 4 DI, 6DQ with time stamp Count, PWM, oversampling

General Information

• Product type designation: TM Timer DIDQ 10x24V

• HW functional status: FS03

• Usable BaseUnits: BU type A0

• I&M data: Yes (I&M0)

• Isochronous mode: Yes

Engineering / Configuration

• STEP 7 TIA Portal: from V13 Update 3

• STEP 7: from V5.5 SP3

Supply Voltage

• Rated: 24 V DC

• Permissible range: 19.2 28.8 V

• Reverse polarity protection: Yes

Input Current

• Max: 50 mA (without load)

Encoder Supply

• Outputs: 1 (24 V)

• Short-circuit protection: Yes

• Max output current: 500 mA (observe derating)

Power Loss

• Typical: 1.5 W

Address Area

• Inputs: 26 byte

• Outputs: 32 byte

Hardware Configuration

• Automatic encoding: Yes

• Mechanical coding element: Type B

Digital Inputs

• Number of inputs: 4

• Para meterizable: Yes

• Features: Time stamp (max 4), Counter (max 3), Counter for incremental encoder (max 1), Oversampling (max 4), HW enable (max 1)

• Input voltage: 24 V DC, signal "0": -5+5 V, signal "1": +11+30 V

• Input current (signal "1"): 2.5 mA

• Cable length: shielded max 1000 m, unshielded max 600 m

Digital Outputs

• Type: Transistor

• Number: 6

• Current-sinking and sourcing: Yes

• Para meterizable: Yes

• Short-circuit protection: Yes

• Max current per output: 0.5 A (0.1 A High Speed)

• Output voltage: signal "0" max 1 V, signal "1" min 23.2 V

• Switching frequency: resistive load max 10 kHz, lamp load max 10 Hz

• Total output current per module: max 3.5 A

Encoder / Counters

• Connectable: Incremental encoder, 24 V, 2-wire sensor

• Max counting frequency: 200 kHz (quadruple evaluation)

• Max encoder cable length: 600 m (depends on frequency)

Isochronous Mode

• Bus cycle time (TDP) min: 375 s

• Jitter max: 1 s

Diagnostics / Status

• Diagnostics function: Yes

• Substitute values: Connectable

• Diagnostic alarm: Yes

• Monitored: Supply voltage, Short-circuit

• LED indicators: PWR green, Channel status, Module diagnostics green/red

Potential Separation / Isolation

• Between channels and backplane bus: Yes

• Isolation tested: 707 V DC

Ambient Conditions

• Horizontal installation: -30 C to 60 C

• Vertical installation: -30 C to 50 C

• Max installation altitude: 5000 m

Decentralized Operation

• Compatible with SIMATIC S7-1500

Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

• Weight: 45 g
