The Siemens Power Supply 6ES7288-0ED10-0AA0 is a durable and reliable industrial power supply designed for various applications. Featuring a sleek black ABS plastic material, this rack-mountable power supply ensures long-term performance with a service period of 12 months. Ideal for exporters, manufacturers, suppliers, and traders, this power supply is a must-have for industrial settings where stable power source is essential.

Siemens SIMATIC PM207/1AC/24VDC/5A

S7-200 SMART Regulated Power Supply

Input: 100–240 V AC
Output: 24 V DC / 5 A

Input Specifications

• Type: 1-phase AC

• Rated Voltage: 100–240 V AC

• Operating Range: 85–264 V AC, 88–370 V DC (wide range)

• Frequency: 47–63 Hz

• Current Consumption:

  • 120 V AC: 2.75 A

  • 230 V AC: 1.15 A

• Inrush Current (max): 30 A

• I²t (max): 1.5 A²·s

• Fuse Protection: Internal, recommended MCB 10 A, characteristic C

• Buffering Time at Rated Output: min. 20 ms

Output Specifications

• Output Voltage: 24 V DC

• Adjustable Range: 22.8 – 26.4 V via potentiometer

• Rated Current: 5 A

• Derating: +55 … +70 °C: 3.5%/K

• Voltage Control Precision:

  • Slow input fluctuation: ±0.1 %

  • Rapid input fluctuation ±15 %: typ. 0.2 %

  • Load step 10–90–10 %: typ. 3 %

• Voltage Peak: max. 50 mV, typ. 25 mV

• Overshoot on Power-On: < 1 %

• Response Time: max. 0.5 s

• Power Loss (typ): 15 W

• Efficiency: 89 %

• Parallel Operation for Power Increase: up to 2 units

Protection & Monitoring

• Short-Circuit Proof: Yes, constant current characteristic

• Current Limitation: 6–7 A (typ. 6.5 A)

• Galvanic Isolation: Yes (Input ↔ Output)

• Operating Protection Class: Class I

• IP Rating: IP20

Safety & Standards

• Certifications:

  • CE: Yes

  • UL / cULus: Yes (UL 508, CSA C22.2 No. 107.1)

  • BIS: Yes (R-41184349)

  • CB प्रमाणपत्र: Yes

  • CCC: Yes

• EMC Standards: EN 55022 Class B, EN 61000-3-2, EN 61000-6-2

• Isolation: Safety extra-low output voltage according to EN 60950-1

Ambient Conditions

• Operating Temperature: -25 … +70 °C (natural convection)

• Storage / Transport Temperature: -40 … +85 °C

• Environmental Category: IEC 60721, Climate class 3K3, 5–95 % RH, no condensation

Mechanical Data

• Connection Type: Screw terminals

  • Input L/N/PE: 0.5–6 mm² single-core / 0.5–4 mm² stranded

  • Output +1/+2/-1/-2: 0.5–4 mm²

• Dimensions: 60 × 100 × 81 mm (W × H × D)

• Installation Width × Height: 100 × 140 mm

• Spacing Requirements: Top/Bottom/Left/Right: 20 mm

• Mounting: DIN Rail EN 60715 (35×7.5/15) or wall mount

• Net Weight: 0.54 kg
