About LOGO 6ED1055-1MB00-0BA2

The LOGO 6ED1055-1MB00-0BA2 is a compact and efficient automation device designed for various industrial applications. This grey-colored device weighs 0.166 kilograms and comes in standard size, suitable for DIN rail mounting. With dimensions of 35.5 x 90 x 58 millimeters (L*W*H), it offers a service period of 12 months, providing reliable performance throughout. Ideal for exporters, manufacturers, suppliers, and traders, this device is a versatile solution for automation tasks.

Siemens LOGO! DM8 12/24R Expansion Module

PS/I/O: 12 V / 24 V / 12 V / 24 V / Relay, 2 MW
I/O: 4 DI / 4 DO for LOGO! 8

Installation & Mounting

• Mounting on 35 mm DIN rail

• Width: 2 spacing units

Supply Voltage

• Rated voltage: 12 V DC, 24 V DC

• Permissible range: 10.828.8 V DC

Digital Inputs

• Number of inputs: 4

• Type: DC

• Signal levels:

  • "0" < 5 V DC

  • "1" > 8.5 V DC

• Input current:

  • "0": max 0.88 mA

  • "1": typ. 1.5 mA

• Input delay: max. 1.5 ms ("01" or "10")

Digital Outputs

• Number of outputs: 4 (Relays)

• Short-circuit protection: No

• Controllable by digital input: Yes

• Switching capacity:

  • Lamp load: max 1,000 W

  • Rated current: 5 A

  • Minimum load current: 100 mA

• Parallel switching: No

• Switching frequency:

  • Resistive load: max 2 Hz

  • Inductive load: max 0.5 Hz

  • Mechanical: max 10 Hz

Relay Output Specs

• Inductive load: max 3 A

• Resistive load: max 5 A

EMC & Protection

• Emission of radio interference: EN 55011, Limit class B (residential)

• Degree of protection: IP20

Certifications & Approvals

• CE, CSA, UL, FM, Marine approval

• Developed according to IEC 61131

Environmental Data

• Environmental product declaration: Yes

• Global warming potential (CO eq):

  • Total: 59.1 kg

  • Production: 5.82 kg

  • Operation: 53.6 kg

  • End of life: -0.373 kg

Ambient Conditions

• Operating temperature: -20 C to 55 C, no condensation

Dimensions

• Width: 35.5 mm

• Height: 90 mm

• Depth: 58 mm
