About SIEMENS G120 AC DRIVE 6SL3210-1PE12-3UL1

Motor Power1.5kWEnclosure TypeIP20Control Method V/F Control Communication Interface ProfinetNet Weight (kg)1,380 Kg SINAMICS Power Module PM240-2 unfiltered with integrated braking chopper 380-480 V 3 AC +10/-10% 47-63 Hz Power high overload: 0.55kW at 200% 3s, 150% 57s, 100% 240 s; Ambient temperature -10 to +50 C; power low overload: 0.75kW at 150% 3s, 110% 57s, 100% 240 s; Ambient temperature -10 to +40 C 196x 73x 165 (HxWxD), FSA Degree of protection IP20 without Control Unit and operating unit Released as of CU firmware version V4.6.

SINAMICS Power Module PM240-2

Article No.: 6SL3210-1PE12-3UL1

Rated Data

Input

• Phases: 3 AC

• Voltage: 380480 V 10 %

• Frequency: 4763 Hz

• Rated current:

  • LO: 2.90 A

  • HO: 2.60 A

Output

• Phases: 3 AC

• Voltage: 400 V IEC / 480 V NEC

• Rated power:

  • LO: 0.75 kW / 1.0 hp

  • HO: 0.55 kW / 0.75 hp

• Rated current:

  • LO: 2.20 A

  • HO: 1.70 A

• Max. output current: 3.40 A

• Pulse frequency: 4 kHz

• Output frequency:

  • Vector control: 0200 Hz

  • V/f control: 0550 Hz

Overload Capability

• LO:

  • 110% for 57 s, 150% for 3 s (300 s cycle)

• HO:

  • 150% for 57 s, 200% for 3 s (300 s cycle)

General Technical Specifications

• Power factor (): 0.85

• Offset factor (cos ): 0.95

• Efficiency (): 0.96

• Sound pressure level (1 m): 72 dB

• Power loss: 0.04 kW

• Filter class: -

Ambient Conditions

• Cooling: Internal air cooling

• Cooling air requirement: 0.005 m/s

• Installation altitude: 1,000 m

• Ambient temperature:

  • Operation LO: -10 40 C

  • Operation HO: -10 50 C

  • Transport/Storage: -25 55 C

• Relative humidity: max. 95 %, no condensation

Connections

• Line side: Plug-in screw terminals, 1.02.5 mm (AWG 1814)

• Motor end: Plug-in screw terminals, 1.02.5 mm (AWG 1814)

• Max. motor cable length:

  • Shielded: 50 m

  • Unshielded: 100 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSA

• Weight: 1.40 kg

• Dimensions: W 73 H 196 D 165 mm
