About SIEMENS G120 CONTROL UNIT 6SL3246-0BA22-1FA0

Article Number: 6SL3246-0BA22-1FA0

SINAMICS G120 Control Unit CU250S-2 PN

• Integrated PROFINET

• Supports vector control and easy positioning (EPOS) via extended function license

• I/O Configuration:

  • 4 configurable DI/DO

  • 6 DI (3 F-DI)

  • 5 DI

  • 3 DO (1 F-DO)

  • 2 AI

  • 2 AO

• Safety Integrated: STO, SBC, SS1

• Additional safety functions available via extended safety license

• Encoder Support: D-CLiQ + HTL/TTL/SSI, Resolver/HTL via terminal

• Protection: IP20

• Interfaces: USB and SD/MMC

Product Family: Ordering Data Overview
Product Lifecycle (PLM): PM300 Active Product

SINAMICS Control Unit CU250S-2 PN

Article No: 6SL3246-0BA22-1FA0

Electrical Data

• Operating voltage via Power Module: DC 24 V

• External power supply: DC 20 29 V

• Max. power consumption: 2.00 A

• Power loss: 12 W

Communication

• Protocols: PROFINET, EtherNet/IP

Inputs / Outputs

Standard Digital Inputs:

• Number: 15

• Switching level 0 1: 11 V

• Switching level 1 0: 5 V

Fail-safe Digital Inputs:

• Number: 3 (uses 2 standard DI)

Digital Outputs:

• As relay changeover contact: 2 (DC 30 V, 0.5 A)

• As relay make contact: 2 (DC 30 V, 0.5 A)

Analog / Digital Inputs:

• Number: 2 (differential input)

Analog Outputs:

• Number: 2 (non-isolated output)

Closed-Loop Control Techniques

• V/f linear / square-law / parameterizable: Yes

• V/f with flux current control (FCC): Yes

• V/f ECO linear / square-law: Yes

• Sensorless vector control: Yes

• Vector control with sensor: Yes

• Encoderless torque control: Yes

• Torque control with encoder: Yes

Ambient Conditions

• Operation temperature: -10 50 C (14 122 F)

• Storage temperature: -40 70 C (-40 158 F)

• Max. relative humidity: 95 %

Connections

• Signal cable conductor cross-section: 0.05 1.50 mm (AWG 28 AWG 16)

Mechanical Data

• Degree of protection: IP20 / UL open type

• Net weight: 0.61 kg (1.34 lb)

• Dimensions:

  • Width: 73 mm (2.87 in)

  • Height: 199 mm (7.83 in)

  • Depth: 67 mm (2.64 in)
