Siemens HMI 6AV2125-2GB23-0AX0

The Siemens 6AV2125-2GB23-0AX0 is a robust and reliable Human-Machine Interface (HMI) designed for efficient industrial automation.

Key Specifications:

• Rated Voltage: 24V DC

• Power Rating: 8.5 W

• Rated Current: 350 mA

• Display: 7-inch TFT widescreen, 800 480 pixels

• Operating Temperature: 0C to 45C

• Humidity Tolerance: Up to 90%

• Frequency: 50/60 Hz

• Mounting: Panel mount

• Protection Level: IP65

• Weight: 1.3 kg

Features:

• High-resolution display for clear monitoring and operation

• Compact and lightweight design for versatile installation

• Durable performance in high-humidity and harsh environments

• Energy-efficient operation for industrial automation tasks

• Suitable for a wide range of industrial applications

This HMI delivers reliable, efficient, and precise performance for modern automation processes.

Datasheet: Siemens 6AV2125-2GB23-0AX0

SIMATIC HMI KTP700F Mobile

7" TFT, 800480 resolution, 16M colors, touch + key operation, 8 function keys, PROFINET, MMC, USB, key switch, acknowledgment button, emergency stop/stop button. Configurable with WinCC Comfort V13 SP1 or higher.

General Information

Product type: KTP700F Mobile

Display

• Type: TFT widescreen, LED backlit

• Size: 7 inch

• Colors: 16,777,216

• Resolution: 800 480 pixels

• Backlight MTBF: 50,000 h

• Backlight dimming: 0100%

Control Elements

Function Keys

• Number of function keys: 8

• Function keys with LEDs: 8

Keyboards

• Numeric keyboard: On-screen

• Alphanumeric keyboard: On-screen

Touch

• Touch screen: Yes

• Multi-touch: No

Special Controls

• Stop button (forced blocking)

• Emergency stop button (illuminated, forced blocking)

• Acknowledgement button (3-stage)

• Key-operated switch

• Illuminated pushbutton

Camera

• Integrated camera: No

Additional I/O for Process Control

• DP direct LEDs (S7 output): 8

• Direct keys (S7 input): 8

• Touch keys as S7 input: 32

Power Supply

• Supply type: 24 V DC

• Voltage range: 19.228.8 V

• Current consumption: 350 mA

• Inrush current (It): 0.135 As

• Power consumption: 8.5 W (typ.)

Processor & Memory

• Processor: ARM

• Flash memory: Yes

• RAM: Yes

• User memory: 12 MB

Indicators

• Power LED: No

• Safety LED: No

• Communication LED: No

• Battery LED: No

• Vibration feedback: No

Clock

• Real-time clock: Yes

• Retentive: Yes

• Synchronizable: Yes

Interfaces

• PROFINET / Industrial Ethernet: 1

• PROFINET IO support: Yes

• USB 2.0: 1

• RS232/RS422/RS485: 0

• Wireless interfaces: None

• SD card slot: 1

Supported Protocols

Industrial Protocols

• PROFINET: Yes

• PROFIsafe: Yes

• EtherNet/IP: Yes

• MODBUS TCP: Yes

Ethernet Features

• TCP/IP, DHCP, SNMP, DCP, LLDP

Web Technologies

• HTTP, HTTPS, HTML, CSS, JavaScript

• XML, ActiveX, Java VM: No

Diagnostics

• Diagnostic info readable: Yes

EMC & Protection

• Emission (EN 55011) Class A

• IP65 (all-round)

Approvals

• CE, cULus, RCM, KC

• Marine approvals: GL, ABS, BV, DNV, KRS, LRS, NK, CCS

Safety

• Performance Level (PL): PLe

• SIL: SIL 3

Environmental Conditions

• Free fall: 1.2 m

• Operating temperature: 045C

• Storage temperature: 2060C

• Humidity: 90%

Operating System

• Windows CE (pre-installed)

HMI Functions

Messages & Alarms

• Alarm classes: 32

• Bit messages: 4000

• Analog messages: 200

• Message buffer: 1024 entries (retentive)

Recipes

• Recipes: 300

• Records/recipe: 500

• Entries/record: 1000

• Internal memory: 2 MB

• Expandable: Yes

Variables & Screens

• Variables/device: 2048

• Variables/screen: 400

• Images: 500

• Objects/screen: 400

• Complex objects/screen: 20

Archiving

• Archives/device: 50

• Entries/archive: 20,000

• Storage: SD/USB/Ethernet

• Formats: CSV, RDB

Supported PLCs

• S7-1200 / S7-1500

• S7-200

• S7-300 / S7-400

• LOGO!

• WinAC / WinAC RTX

• SINUMERIK (no NC channel)

• SIMOTION

• Allen Bradley (EtherNet/IP)

• Mitsubishi (MC TCP/IP)

• Modicon (Modbus TCP/IP)

• OPC UA Client + Server

Options & Accessories

• Backup/restore

• Simulation

• Device switchover

• Memory card (MMC/SD)

• USB memory

• Network camera

Mechanical Data

• Front housing: Plastic

• Weight (without packaging): 1.3 kg

• Weight (with packaging): 1.4 kg

Technical Details
