SIEMENS HMI 6AV2125-2JB03-0AX0

About SIEMENS HMI 6AV2125-2JB03-0AX0

SIMATIC HMI KTP900 Mobile

• Display: 9.0" TFT, 800 x 480 pixels, 16 million colors
• Operation: Key & touch, 10 function keys
• Interfaces: 1x PROFINET/Industrial Ethernet, 1x USB, 1x multimedia card
• Configuration: WinCC Comfort V13 SP1

General Information

• Product Type: KTP900 Mobile

• Display: TFT widescreen with LED backlighting

• Screen Diagonal: 9"

• Color Display: Yes, 16,777,216 colors

• Resolution: 800 x 480 pixels

• MTBF Backlighting: 50,000 h

• Dimmable Backlight: Yes, 0100%

Control Elements

• Function Keys: 10 (all with LEDs)

• Onscreen Numeric & Alphanumeric Keyboard: Yes

• Touch Screen: Yes (not multi-touch)

• Illuminated Pushbutton: Yes

Camera

• Integrated: No

Operator Control Expansions

• DP Direct LEDs: 10 (F1F10)

• Direct Keys (S7 I/O): 10

• Direct Keys (Touch Buttons as S7 I/O): 32

Supply Voltage & Power

• Rated Voltage: 24 V DC

• Permissible Range: 19.2 28.8 V DC

• Current Consumption: 450 mA

• Inrush Current (It): 0.135 As

• Active Power Input: 11 W

Processor & Memory

• Processor: ARM

• Flash & RAM: Yes

• User Memory: 12 MB

Interfaces

• Industrial Ethernet / PROFINET: 1

• USB 2.0: 1

• SD Card: 1

• Wireless: None

Supported Protocols

• PROFINET IO, EtherNet/IP, TCP/IP, DHCP, SNMP, DCP, LLDP, HTTP, HTTPS, CSS, JavaScript, MODBUS

• PROFIBUS, PROFIsafe: No

Diagnostics & EMC

• Diagnostics Readable: Yes

• EMC: EN 55 011, Class A (industrial)

• IP Rating: IP65 (all-round protection)

Standards / Approvals

• CE, cULus, RCM, KC

• Marine Approvals: GL, ABS, DNV, LRS, Class NK

• Safety Functions: Not applicable

• Hazardous Area Use: No

Ambient Conditions

• Operating Temp: 0 45 C

• Storage/Transport Temp: -20 60 C

• Relative Humidity: Max 90%

• Free Fall: Max 1.2 m

Operating System

• Pre-installed: Windows CE

• Alarm & Message Systems: Yes

• Recipe Management: Yes

• Process Value Display & Input: Yes

Configuration Software

• WinCC Comfort/Advanced/Professional (TIA Portal): Yes

• Other WinCC Flexible / STEP 7 options: No

Languages

• Online/Runtime Languages: 32

• Project Languages: 32

Functionality

• Libraries: Yes

• Web Browser & PDF Viewer: Yes

• Media Player: No

• SIMATIC WinCC Sm@rtServer & Audit: Yes

• Task Planner: Time-controlled: Yes

Variables & Images

• Variables per Device: 2,048

• Variables per Screen: 400

• Configurable Images: 500

• Objects per Image: 400

• Complex Objects per Screen: 20

Archiving

• Archives per Device: 50

• Entries per Archive: 20,000

• Supported Storage: Memory Card, USB, Ethernet

• Data Formats: CSV, RDB

Security & Users

• User Groups: 50

• Users: 50

• User Rights: 32

• Password Export/Import: Yes

• SIMATIC Logon: Yes

Process Coupling

• Compatible with: S7-1200, S7-1500, S7-200, S7-300/400, LOGO!, WinAC, SINUMERIK, SIMOTION, Allen Bradley (EtherNet/IP), Mitsubishi (MC TCP/IP, FX), Modicon (Modbus TCP/IP), OPC UA Client/Server

Service Tools

• Backup/Restore: Manual & Automatic

• Simulation & Device Switchover: Yes

Peripherals / Options

• Printer, USB memory, SIMATIC HMI MM / SD Cards, Network Camera: Yes

• Additional Software Components: Loadable (SIMATIC options)

Mechanics / Material

• Enclosure Material: Plastic

• Weight: 1.5 kg (without packaging), 1.6 kg (with packaging)
