About SIEMENS HMI 6AV6647-0AF11-3AX0

Siemens HMI 6AV6647-0AF11-3AX0 (SIMATIC TP177B 6 Touch Panel)

The Siemens 6AV6647-0AF11-3AX0 is a SIMATIC TP177B HMI (Human-Machine Interface) with a 6-inch touchscreen display, designed for industrial automation applications. It provides intuitive process visualization, monitoring, and control for machines and systems.

Key Features:

• 6 TFT Color Touchscreen - High-resolution (320x240 pixels, 256 colors) for clear visualization

• Flexible Communication Interfaces: PROFIBUS DP/MPI (RS485), Ethernet (Profinet), USB & RS232 Ports

• User-Friendly Operation - Touchscreen and function keys for easy control

• Data Logging & Alarms - Stores and displays process data, alarms, and messages

• Recipe Management - Supports process parameter storage and retrieval

• Compact & Rugged Design - Ideal for harsh industrial environments

• Compatible with WinCC Flexible & TIA Portal - Easy configuration and programming

Technical Specifications:

• Display Type: 6 TFT Color Touchscreen

• Resolution: 320 x 240 pixels (256 colors)

• Communication: PROFIBUS DP/MPI (RS485), Ethernet (Profinet), RS232 & USB Ports

• Memory: 2MB Flash + MMC/SD Card Support

• Power Supply: 24V DC

• Operating Temperature: 0 Degree C to +50 Degree C

• Protection Rating: IP65 (front), IP20 (rear)

Applications:

• Machine & Process Control - User-friendly interface for operators

• Factory Automation - Real-time monitoring and control of production lines

• Energy Management - Integration with automation systems for efficiency

• Industrial Equipment - Used in packaging, CNC machines, and material handling

The Siemens 6AV6647-0AF11-3AX0 (SIMATIC TP177B 6 HMI) is a powerful and compact touch panel, offering seamless integration, reliable operation, and intuitive control for industrial automation applications.

SIMATIC HMI KTP1000 Basic Color PN

Basic Panel, key/touch operation, 10" TFT display, 256 colors, PROFINET interface.Configurable with WinCC flexible 2008 SP2 Compact / WinCC Basic V10.5 / STEP 7 Basic V10.5.Contains open-source software (see enclosed CD).

General Information

• Product type designation: KTP1000 Basic color PN

Display

• Display type: TFT

• Screen diagonal: 10.4 in

• Width: 211.2 mm

• Height: 158.4 mm

• Colors: 256

• Resolution: 640 480 pixels

Backlighting

• MTBF: 50,000 h

• Dimmable: No

Control Elements

Function keys

• Number of function keys: 8

• Function keys with LEDs: 0

• Keys with LED: No

• System keys: No

Keyboards

• Numeric keyboard: Yes (Onscreen)

• Alphanumeric keyboard: Yes (Onscreen)

Touch

• Touch screen: Yes, analog-resistive

Installation / Mounting

• Mounting position: Vertical

• Rack/Walls/Portrait: No

• Landscape format: Yes

• Max tilt angle without external ventilation: 35

Supply Voltage

• Type: DC

• Rated value: 24 V DC

• Permissible range: 19.228.8 V DC

Input Current

• Current consumption: 0.6 A

• Starting inrush It: 0.2 As

Power

• Active power input (typ.): 15 W

Processor & Memory

• Processor: 32-bit RISC

• Flash: Yes

• RAM: Yes

• User memory: 2 MB

Acoustics

• Buzzer: Yes

• Speaker: No

Clock

• Hardware clock: No

• Software clock: Yes

• Retentive: No

• Synchronizable: Yes

Interfaces

• Industrial Ethernet: 1

• RS485 / RS422 / RS232: 0

• USB: 0

• SD card slots: 0

• Software interfaces: No

Industrial Ethernet Status LEDs

• LEDs: 2

Protocols

• PROFINET: Yes

• PROFINET IO: No

• IRT: No

• PROFIBUS: No

• Ethernet/IP: Yes

• MPI: No

Ethernet Protocols

• TCP/IP, DHCP, SNMP, DCP, LLDP: Yes

Web

• HTTP: No

• HTML: No

Other Protocols

• CAN: No

• MODBUS: Yes (TCP/IP)

Diagnostics

• Diagnostic information readable: No

Protection

• Front: IP65

• Rear: IP20

NEMA (front)

• Type 4: Yes

• Type 4X: Yes

Approvals

• CE, cULus, RCM, KC: Yes

Hazardous Areas

(All No except Marine approvals)

Marine Approvals

GL, ABS, BV, DNV, LRS, Class NK: Yes
PRS: No

Ambient Conditions

Operating Temperature

• Vertical installation: 0 to 50C

• At maximum tilt: 0 to 40C

Storage/Transport

• 20 to +60C

Humidity

• Max 90%, non-condensing

Operating System

• Proprietary OS

• Windows CE: No

Functions

• Message indicator: Yes

• Alarm system: Yes

• Process value display/default: Yes

• Recipe management: Yes

Configuration Software

Supported:

• STEP 7 Basic/Professional (TIA Portal)

• WinCC flexible Compact/Standard/Advanced

• WinCC Basic/Comfort/Advanced/Professional (TIA Portal)

Languages

• Online/runtime languages: 5

• Project languages: 32

WinCC Functionality

• Libraries: Yes

• Web browser: No

• Sm@rtServer: No

Task Planner

• Time-controlled: No

• Task-controlled: Yes

Message System

• Alarm classes: 32

• Bit messages: 200

• Analog messages: 15

• System messages HMI: Yes

• Characters per message: 80

• Process values per message: 8

Message Buffer

• Entries: 256

• Circulating, retentive, maintenance-free: Yes

Recipe Management

• Recipes: 5

• Data records per recipe: 20

• Entries per record: 20

• Internal memory: 40 KB

• Expandable: No

Variables

• Variables per device: 500

• Per screen: 30

• Limit values, multiplexing: Yes

• Structures: No

• Arrays: Yes

Images

• Configurable images: 50

• Permanent window: Yes

• Global image: Yes

• PLC-based image selection: Yes

Image Objects

Text fields, I/O fields, graphics, symbols, date/time, switches, buttons, geometric objects: Yes

Complex Objects

• Alarm view, trend view, recipe view: Yes

• Status/control, Sm@rtClient, f(x) trend, system diagnostics, media player: No

Lists

• Text lists: 150

• Entries per list: 30

• Graphics lists: 100

• Entries: 30

Archiving

• Archives: 0

Security

• User groups: 50

• Rights: 32

• Users: 50

• Password export/import: No

• SIMATIC Logon: No

Transfer (Upload/Download)

• Ethernet: Yes

• MPI/PROFIBUS/USB/external storage: No

Process Coupling

Supported: S7-1200, S7-1500, S7-200, S7-300/400, LOGO!, WinAC, Modicon (Modbus), Mitsubishi (MC TCP/IP), Allen Bradley (EtherNet/IP)

Service Tools

• Manual backup/restore: Yes

• Automatic: No

• Simulation: Yes

• Device switchover: Yes

Peripherals

• Printer: No

• Memory cards: No

• USB memory: No

Material

• Front enclosure material: Plastic

Dimensions

• Width (front): 335 mm

• Height: 275 mm

• Cutout: 310 248 mm

• Depth: 60 mm

Weight

• Without packaging: 2.65 kg

• With packaging: 3.38 kg
