SIEMENS LOGO PLC 6ED1055-1HB00-0BA2

The SIEMENS LOGO PLC 6ED1055-1HB00-0BA2 is a compact and versatile programmable logic controller designed for seamless automation tasks. With a rated voltage of 24V DC, this PLC delivers reliable performance for various automation applications. Its compact dimensions of 35.5 x 90 x 58 mm and DIN rail mounting type ensure easy installation in challenging industrial environments. The device operates efficiently within a temperature range of -20C to +55C and maintains optimal functionality even under high humidity levels of up to 95%. Offering a frequency range of 47-63 Hz and an IP20 protection level, it ensures safety and consistent operation. The grey-colored PLC is a robust solution for improving workflow automation while adhering to high durability standards.

Data Sheet: 6ED1055-1HB00-0BA2

LOGO! DM8 24R Expansion Module

PS/I/O: 24V / 24V / Relay | 4 DI / 4 DO | AC/DC/NPN Input | For LOGO! 8

Installation / Mounting

• Mounting on 35 mm DIN rail

• Width: 2 spacing units

Supply Voltage

DC Supply

• Rated value: 24 V DC

• Permissible range: 20.4 V to 28.8 V

AC Supply

• Rated value: 24 V AC

• Line frequency: 47 Hz to 63 Hz

Digital Inputs

• Number of inputs: 4

• Type of input voltage: AC/DC

Input Voltage Levels

• Signal "0": < 5 V AC/DC

• Signal "1": > 12 V AC/DC

Input Current

• Signal "0" (max): 1.1 mA

• Signal "1" (typical): 2.63 mA

Input Delay

• 0 1: max. 1.5 ms

• 1 0: max. 15 ms

Digital Outputs

• Number of outputs: 4 (Relay type)

• Short-circuit protection: No

• Can control a digital input: Yes

Switching Capacity

• Lamp load: max. 1000 W

Output Current

• Rated current at signal "1": 5 A

• Minimum load: 100 mA

Parallel output switching

• For uprating: Not allowed

Switching Frequency

• Resistive load: max. 2 Hz

• Inductive load: max. 0.5 Hz

• Mechanical: max. 10 Hz

Relay Output Specifications

• Inductive load: max. 3 A

• Resistive load: max. 5 A

EMC

• EN 55011, Limit Class B (residential areas): Yes

Protection

• IP Rating: IP20

Standards / Approvals

• CE: Yes

• CSA: Yes

• UL: Yes

• FM: Yes

• Developed per IEC 61131: Yes

• VDE 0631: Yes

• Marine approval: Yes

Environmental Footprint

• Total CO equivalent: 59.1 kg

• During production: 5.82 kg

• During operation: 53.6 kg

• End of life: 0.373 kg

Ambient Conditions

• Operating temperature: 20 C to +55 C (no condensation)

Dimensions

• Width: 35.5 mm

• Height: 90 mm

• Depth: 58 mm
