Siemens PLC 6ES7214-1AG40-0XB0

Boost your automation systems with the Siemens PLC 6ES7214-1AG40-0XB0, a high-performance and flexible controller designed for medium to large-scale industrial applications. The Siemens PLC 6ES7214-1AG40-0XB0 is part of the powerful Siemens S7-1200 series, known for its advanced processing capabilities, modular design, and seamless integration with other Siemens automation products. Ideal for industries like manufacturing, machine building, and process control, this PLC ensures reliable and efficient control of complex systems.

The Siemens PLC 6ES7214-1AG40-0XB0 offers enhanced functionality with its integrated I/O capabilities, fast communication protocols, and high-speed processing power. It supports a wide range of expansion options, allowing for easy scalability as your automation needs grow. The Siemens PLC 6ES7214-1AG40-0XB0 is also designed for energy efficiency, reducing operational costs while maintaining optimal performance in demanding environments.

At Naksh Technology Solution LLP, we provide expert integration and support for the Siemens PLC 6ES7214-1AG40-0XB0, ensuring it fits perfectly into your existing systems. Enhance your control and automation capabilities with the reliable, scalable, and high-performing Siemens PLC 6ES7214-1AG40-0XB0, designed to meet the challenges of modern industrial applications.

Data Sheet: SIMATIC S7-1200 CPU 1214C

Article No.: 6ES7214-1AG40-0XB0

General Information

• Compact CPU, DC/DC/DC

• Onboard I/O: 14 DI 24 V DC, 10 DO 24 V DC, 2 AI 010 V DC

• Power supply: DC 20.428.8 V

• Program/data memory: 150 KB / 4 MB

Firmware & Engineering

• Firmware version: V4.7

• Programming: STEP 7 V20 or higher

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 20.428.8 V DC

• Reverse polarity protection: Yes

Input Current

• CPU only: 500 mA

• With all expansion modules: 1,500 mA max

• Inrush current: 12 A at 28.8 V

Output Current

• Backplane bus (5 V DC) max: 1,600 mA

• Encoder supply: 24 V L+ minus 4 V DC min.

Power Loss

• Typical: 12 W

Memory

• Work memory: 150 KB

• Load memory: 4 MB

• Backup: Yes, maintenance-free, without battery

CPU Processing Times

• Bit operations: 0.08 s

• Word operations: 1.7 s

• Floating point arithmetic: 2.3 s

Digital Inputs

• Number: 14 (6 usable for high-speed counting)

• Source/sink input

• Rated voltage: 24 V DC

• Input delay: 0.1 s 20 ms (parameterizable)

• Cable length: Shielded max 500 m, unshielded max 300 m

Digital Outputs

• Number: 10 (4 high-speed outputs)

• Rated current: 0.5 A

• Output voltage: 024 V

• Switching frequency: Max 100 kHz (pulse outputs)

Analog Inputs

• Number: 2

• Voltage range: 010 V

• Input resistance: 100 k

• Cable length: Max 100 m (twisted & shielded)

Encoder

• Connectable: 2-wire sensor

Communication Interfaces

• PROFINET IO Controller / Device

• Transmission rate: Max 100 Mbit/s

• Protocols: TCP/IP, UDP, ISO-on-TCP, MODBUS, OPC UA Server

• Ports: 1 RJ45

• Web server supported

• Media redundancy: Not supported

Counters, PID, and Positioning

• Counters: 6, max 100 kHz

• Controlled positioning axes: Max 8

• Pulse outputs: 4, limit frequency 100 kHz

• PID controller: Yes

Potential Separation

• Digital inputs: No

• Digital outputs: Yes (between channels in groups)

EMC & Protection

• Interference immunity: IEC 61000 series

• Emission limits: EN 55011 Class A/B

• Protection class: IP20

Ambient Conditions

• Operation temperature: -20 60 C

• Storage/transport: -40 70 C

• Altitude: -1,000 5,000 m

• Humidity: Max 95% (non-condensing)

• Vibration: 2 g wall mounting, 1 g DIN rail

• Shock: 15 g, 11 ms

Programming & Security

• Languages: LAD, FBD, SCL

• User program protection / password / block protection: Yes

• User administration: 42 users, 14 groups, 20 roles

Dimensions & Weight

• Width: 110 mm, Height: 100 mm, Depth: 75 mm

• Weight: 415 g
