SIEMENS PLC 6ES7223-1BL32-0XB0

About SIEMENS PLC 6ES7223-1BL32-0XB0

Manufacturer Series: S7 1200
Communication Protocols: RS232
Mounting Type: Stand-alone
Output Type: Digital

6ES7223-1BL32-0XB0

SIMATIC S7-1200, Digital I/O SM 1223, 16 DI/16 DO, 16 DI 24 V DC, Sink/Source, 16 DO, transistor 0.5 A

We have excellent range of Siemens PLC S7-1200 which have an excellent designs and they provide a high quality of integration between the controllers and provide an effective performance to the clients. It offers very accurate and precise carrying out of the automation tasks.

Features:

• Scalable and flexible designs

• Reasonable price

• Reliable

• Integrated Profinet System

• PID Functionality for close looped systems

Specifications:

The SIMATIC S7-1200 system is available in five models: CPU 1211C, CPU 1212C, CPU 1214C, CPU 1215C and CPU 1217C. Each can be extended to meet any machine's requirement. The digital and analog I/Os can easily be expanded without affecting the physical size of the controller by installing a signal board inside the front of the CPUs. Connecting signal modules at the right side of the CPU increases the digital and analog I/O capacity even further.

• CPU 1212C can accommodate two, and CPU 1214C, CPU 1215C and CPU 1217C up to eight signal modules.

• All SIMATIC S7-1200 CPUs can be equipped with up to three communication modules on their left side for point-to-point serial communication, PROFIBUS Master/Slave, GPRS communication, AS-i and more Fieldbus systems.

CPU Versions:

• CPU 1211C comes in three versions AC/DC/RLY, DC/DC/DC and DC/DC/RLY onboard 6DI/4DO, 2AI

• CPU 1212C comes in three versions AC/DC/RLY, DC/DC/DC and DC/DC/RLY onboard 8DI/6DO, 2AI

• CPU 1214C comes in three versions AC/DC/RLY, DC/DC/DC and DC/DC/RLY onboard 14DI/10 DO, 2AI

• CPU 1215C comes in three versions AC/DC/RLY, DC/DC/DC and DC/DC/RLY onboard 14DI/10 DO, 2AI/2AO

• CPU 1217C DC/DC/DC, Onboard 14DI/10 DO, 2AI/2AO

All Input Output Expansion Modules: (DI, DO, AI, AO)
Communication Modules: (CB1241, CM1241)

General Information

• Product: SIMATIC S7-1200, Digital I/O SM 1223

• Type: DI 16x24 V DC, DQ 16x24 V DC

• Digital Inputs / Outputs: 16 DI / 16 DO

• DO Type: Transistor, 0.5 A

• Supply Voltage: 24 V DC (Permissible: 20.428.8 V)

• Backplane Bus Current: Max 185 mA

• Power Loss: Typ. 4.5 W

Digital Inputs

• Number of Inputs: 16 (groups of 2)

• Type: DC, Sink/Source

• Input Voltage: 24 V DC

• Signal Levels: "0" = 5 V DC, "1" = 15 V DC

• Input Current: "0" max. 1 mA, "1" typ. 4 mA

• Input Delay (parameterizable): 0.212.8 ms

• Cable Length: Shielded max 500 m, Unshielded max 300 m

Digital Outputs

• Number of Outputs: 16 (groups of 1)

• Output Type: Transistor, 0.5 A

• Switching Capacity:

  • Resistive load: 0.5 A

  • Lamp load: 5 W

• Output Voltage: 24 V DC

• Output Current: Rated 0.5 A, Residual 0.01 mA

• Output Delay: "0""1" max 50 s, "1""0" max 200 s

• Total Current per Group: Max 8 A (horizontal installation 50C)

• Cable Length: Shielded max 500 m, Unshielded max 150 m

Interrupts / Diagnostics

• Diagnostic Alarm: Yes

• LED Indications: Inputs and outputs

Potential Separation

• DI Channels: Groups of 2

• DO Channels: Groups of 1

• Between Channels & Backplane Bus: 500 V AC

Protection & Standards

• IP Rating: IP20

• Approvals: CE, CSA, UL/cULus, FM, RCM, KC, Marine

Ambient Conditions

• Operating Temperature: -20 C to 60 C (horizontal), -20 C to 50 C (vertical)

• Storage Temperature: -40 C to 70 C

• Relative Humidity: Max 95% (non-condensing)

• Air Pressure: 6601080 hPa

• Free Fall: Max 0.3 m, 5 times in packaging

• Permissible Temperature Change: 3 C / min

Mechanics / Dimensions

• Enclosure Material: Plastic

• Width: 70 mm

• Height: 100 mm

• Depth: 75 mm

• Weight: 310 g

• Front Connector: Required
