About Siemens PLC 6ES7288-1ST30-0AA1

Looking for a reliable Siemens PLC for industrial automation? Naksh Technology Solution LLP offers the Siemens 6ES7288-1ST30-0AA1, a SIMATIC S7-200 SMART CPU ST30 designed for efficient and cost-effective automation control.

Key Features:

• Product type: Siemens SIMATIC S7-200 SMART PLC

• Model number: 6ES7288-1ST30-0AA1

• Processor type: CPU ST30

• Input/output: 18 digital inputs, 12 digital outputs

• High-speed processing for real-time control applications

• Compact and space-saving design for easy installation

• Suitable for machine control, process automation, and industrial automation applications

Why Choose Naksh Technology Solution LLP:

• Authorized supplier of Siemens automation products

• Competitive pricing with expert technical support

• Fast and reliable delivery across India

• High-quality products for industrial automation and process control

Order Now:
Upgrade your automation system with the Siemens PLC 6ES7288-1ST30-0AA1. Contact Naksh Technology Solution LLP today for the best deals.

Siemens SIMATIC S7-200 SMART

CPU ST30, Standard CPU, DC/DC/DC
Onboard I/O: 18 DI 24 V DC, 12 DQ 24 V DC
Program/Data Memory: 30 KB
Web Server: Yes

General Information

• Product type designation: CPU ST30 DC/DC/DC

• Engineering software: STEP 7 Micro/WIN SMART

• Mounting: Standard DIN rail

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 20.4 28.8 V DC

• Current consumption: Max 624 mA @ 24 V DC

• Inrush current: Max 6 A @ 28.8 V DC

Outputs

• Current output: Max 300 mA @ 24 V DC (Sensor Power)

• Backplane bus (5 V DC): Max 1.4 A

Power Loss

• Max: 12 W

Memory

• Program memory: 18 KB

• User data memory: 12 KB

• Memory type: DDR, Flash, RAM

• Micro Memory Card: Optional microSDHC

• Backup: Maintenance-free, RTC requires 7 days

CPU Processing Times

• Bit operations: Typ. 150 ns / instruction

• Word operations: Typ. 1.2 s / instruction

• Floating point arithmetic: Typ. 3.6 s / instruction

Address Area

• Inputs: 144 bytes (256 DI bits + 56 analog words)

• Outputs: 144 bytes (256 DO bits + 56 analog words)

Digital Inputs

• Number of DI: 18 (6 for HSC High-Speed Counting)

• Type: Source/sink

• Rated voltage: 24 V DC

• Input current: Typ. 4 mA

• Input delay: Parameterizable (0.2 12.8 ms)

• Cable length:

  • Shielded: Max 500 m (50 m for HSC inputs)

  • Unshielded: Max 300 m

Digital Outputs

• Number of DO: 12 (3 High-Speed Pulse Outputs)

• Switching capacity:

  • Resistive load: Max 0.5 A

  • Lamp load: Max 5 W

• Output voltage (signal 1): Min. 20 V DC

• Output current: Rated 0.5 A, residual max 10 A

• Output delay: 01 max 3 s, 10 max 200 s

• Pulse output switching frequency: Max 100 kHz

Relay Outputs

• Number: 0

Interfaces

1. PROFINET (Ethernet RJ45)

   • Isolated: 1,500 V AC

   • Transmission rate: 10/100 Mbit/s

   • Autonegotiation & Autocrossing: Yes

   • PROFINET IO Controller: Max 8 devices, Update time 4 ms

   • I-Device support since FW V2.5

2. RS 485

   • Max 187.5 kbps

   • Supports PROFIBUS DP via CM DP module

   • S7 communication: Yes (Client/Server)

Integrated Functions

• PID controller: Max 8 loops

• Pulse outputs: 3

EMC / Interference Immunity

• Static electricity: 8 kV air, 4 kV contact (IEC 61000-4-2)

• High-frequency fields: 10 V/m, 80 1,000 MHz

• Cable-borne interference: 2 kV (IEC 61000-4-4)

• Conducted interference: EN 61000-6-4 (industrial areas)

Ambient Conditions

• Operation temperature: -20 60 C (horizontal), -20 50 C (vertical)

• Storage temperature: -40 70 C

• Air pressure: 660 1,080 hPa

• Relative humidity: Max 95% (non-condensing)

• Free fall: Max 0.3 m, 5 times in package

• Installation altitude: -1,000 2,000 m

Programming Languages

• LAD, FBD, STL

Dimensions & Weight

• Width Height Depth: 110 100 81 mm

• Weight: 375 g
