Siemens PLC IO Module ET200S 6ES7135-4GB01-0AB0

About Siemens PLC IO Module ET200S 6ES7135-4GB01-0AB0

The Siemens PLC IO Module ET200S 6ES7135-4GB01-0AB0 is a robust and reliable industrial automation component in a standard size, designed in a sleek grey color for seamless integration into industrial setups. This electrically powered module ensures efficient performance and comes with a 1-year warranty. Ideal for exporters, manufacturers, suppliers, and traders, this new condition module promises high-quality output for various industrial applications.

General Information

• Product: SIMATIC ET 200S, Analog Output Module

• Article No.: 6ES7135-4GB01-0AB0

• Type: 2 AO I, 15 mm width

• Output: 20 mA; 420 mA, 1314 bit resolution

• Cycle Time: <1.5 ms (all channels)

• LED: SF (Group Fault)

Supply Voltage

• Rated Value (L+): 24 V DC (from power module)

• Reverse Polarity Protection: Yes

• Input Current:

  • From L+: max 150 mA (without load)

  • From backplane bus: max 10 mA

• Power Loss: Max 2 W

Address Area

• Max Address Space per Module: 4 bytes

Analog Outputs

• Number of Outputs: 2

• No-load Voltage (max): 18 V

• Output Ranges (Current):

  • 20 mA

  • 420 mA

• Actuator Connection:

  • Two-wire: Yes

  • Four-wire: No

• Load Impedance:

  • Max: 500

  • Inductive: 1 mH max

Destruction Limits

• Voltages at Outputs to MANA: Max 15 V continuous, 75 V for 1 s

• Current: Max 50 mA DC

Cable Length

• Shielded: Max 200 m

Analog Value Generation

• Resolution: 1314 bit (including sign)

• Settling Time:

  • Resistive load: 0.1 ms

  • Capacitive/Inductive load: 0.5 ms

Errors / Accuracy

• Operational error (full temperature range): 0.5 %

• Basic error (25 C): 0.3 %

Diagnostics / Status

• Substitute Values: Connectable (065535, must be within rated range)

• Diagnostic Functions: Wire-break, group error

• LED Indicators: Group Fault SF (red)

• Response to CPU/Master STOP: Output current de-energized / substitute value / hold last value

Potential Separation & Isolation

• Between channels: No

• Between channels and backplane bus: Yes

• Between channels and L+: Yes

• Tested Isolation: 500 V DC

Dimensions & Weight

• Width: 15 mm

• Height: 81 mm

• Depth: 52 mm

• Weight: 40 g
