About SIEMENS PLC MODULES 6ES7131-6BF01-0BA0

SIEMENS PLC MODULES 6ES7155-6AU01-0CN0 is an advanced communication module designed to integrate seamlessly with the SIMATIC S7-1500 PLC system. This module is essential for enabling reliable, high-speed communication between the PLC and other devices in the industrial automation network, ensuring smooth data exchange and optimal performance. The SIEMENS PLC MODULES 6ES7155-6AU01-0CN0 is engineered for demanding industrial applications, including manufacturing automation, process control, and more. It provides excellent compatibility with the S7-1500 PLC, making it ideal for complex control systems that require rapid and accurate communication. By using SIEMENS PLC MODULES 6ES7155-6AU01-0CN0, industries can optimize their automation systems, ensuring high system reliability and efficiency in real-time data transfer. For more details, pricing, or inquiries about SIEMENS PLC MODULES 6ES7155-6AU01-0CN0, please contact Naksh Technology Solution LLP, your trusted supplier of Siemens PLC products.

Data Sheet: 6ES7131-6BF01-0BA0

SIMATIC ET 200SP Digital Input Module (DI 8x24V DC Standard, Type 3)

1. General Information

• Product: DI 8x 24V DC Standard (Type 3, IEC 61131)

• Sink input (PNP, P-reading)

• Packing unit: 1 piece

• BaseUnit: BU type A0

• Colour code: CC01

• Input delay: 0.05 ms 20 ms

• Module diagnostics for:

  • Short-circuit of sensor supply

  • Wire break

  • Supply voltage

2. Product Details

• Product designation: DI 8x24 VDC ST

• Hardware status: FS02

• Firmware version: V0.0 (no FW update)

• I&M data: Yes (I&M0I&M3)

• Isochronous mode: No

• Suitable for PROFINET R1 IMs: Yes

3. Engineering Compatibility

• STEP 7 TIA Portal: from V14

• STEP 7: from V5.5 SP3

• PCS 7: from V8.1 SP1

• PCS neo: from V3.1

• PROFIBUS GSD: Revision 3 & 5+

• PROFINET GSDML: V2.3

4. Operating Modes

• DI mode: Yes

• Counter / Oversampling / MSI: No

5. Supply Voltage

• Rated DC voltage: 24 V

• Permissible range: 19.2 28.8 V

• Reverse polarity protection: Yes

6. Input Current

• Max. current consumption: 50 mA

7. Encoder Supply

• Outputs: 8

• Output voltage: min. 19.2 V

• Short-circuit protected: Yes

• Max. current:

  • Per channel: 700 mA

  • Per module: 700 mA

8. Power Loss

• Typical power loss: 1 W

9. Address Area

• Inputs: 1 byte + 1 byte QI info

10. Hardware Configuration

• Automatic encoding: Yes

• Mechanical coding: Type A

• Suitable BaseUnits:

  • 1-wire: A0

  • 2-wire: A0

  • 3-wire: A0 with AUX

  • 4-wire: A0 + potential distributor

11. Digital Inputs

• Number of inputs: 8

• Parameterizable: Yes

• Input type: P-reading (sink input)

• IEC 61131 Type 3: Yes

Input Voltage

• Rated: 24 V

• Signal 0: 30 +5 V

• Signal 1: +11 +30 V

Input Current

• Typ. at 1: 2.5 mA

Input Delay (parameterizable)

• 0.05 / 0.1 / 0.4 / 0.8 / 1.6 / 3.2 / 12.8 / 20 ms
  (+ additional 30500 s depending on cable length)

12. Cable Length

• Shielded: up to 1000 m

• Unshielded: up to 600 m

13. Encoder Support

• 2-wire sensors: Yes

  • Max quiescent current: 1.5 mA

14. Diagnostics

• Diagnostic alarm: Yes

• Supply voltage monitoring: Yes

• Encoder supply monitoring: Yes

• Wire break: Yes (module-wise)

• Short-circuit: Yes

• Diagnostic info readable: Yes

LED Indications

• PWR: Green

• Channel status: Green

• Module diagnostic: Green/Red

• Channel diagnostic: No

15. Potential Separation

• Between channels: No

• Channels Backplane bus: Yes

• Channels Electronics power: No

• Test voltage: 707 V DC

16. Ambient Conditions

• Operating temperature:

  • Horizontal: 30 +60 C

  • Vertical: 30 +50 C

• Installation altitude: up to 5000 m
  (Restrictions above 2000 m)

17. Dimensions

• Width: 15 mm

• Height: 73 mm

• Depth: 58 mm

18. Weight

• Approx.: 28 g
