About SIEMENS PLC MODULES 6ES7288-3AM06-0AA0

Product: Siemens SIMATIC S7-200 SMART Analog Input/Output Module
Part Number: 6ES7288-3AM06-0AA0

The Siemens S7-200 SMART Analog Input/Output Module is designed for the S7-200 SMART PLC system, providing reliable analog signal processing for industrial applications.

Key Features:

• Analog Inputs: 4 channels supporting 0-10 V, 0-5 V, 0/4-20 mA, 5 V, or 2.5 V signals with 12-bit resolution.

• Analog Outputs: 2 channels supporting 0-10 V, 0-5 V, 0/4-20 mA, 5 V, or 2.5 V signals with 12-bit resolution.

• Signal Types Supported: 0-10 V, 0-5 V, 0/4-20 mA, 5 V, 2.5 V, and 4-20 mA, 10 V.

• Resolution: 12-bit for analog inputs and 11-bit for 4-20 mA / 10 V output signals.

Applications:

• Industrial automation systems requiring precise analog signal control.

• Process control, monitoring, and measurement systems.

SIMATIC S7-200 SMART Analog I/O Module SM AM06

Article No.: 6ES7288-3AM06-0AA0
Type: 4 AI / 2 AO, Voltage/Current, 12-bit (AI) / 11-bit (AO) resolution

General Information

• Product type: SM AM06, AI 4x12 bit, AQ 2x11 bit

• Configuration in RUN (CiR): Not possible

Supply Voltage

• Type: DC

• Rated value: 24 V (-15 / +20 %)

• Permissible range: 20.428.8 V

• Current consumption:

  • Typ. 60 mA

  • From backplane bus 5 V DC: Typ. 80 mA

• Power loss: Typ. 2 W

Analog Inputs (AI)

• Number of inputs: 4

• Input ranges:

  • Voltage: 10 V, 5 V, 2.5 V

  • Current: 020 mA

  • Thermocouple/Resistance/RTR: No

Input Resistances

• Voltage inputs: 9 M

• Current input (020 mA): 250

Analog Outputs (AO)

• Number of outputs: 2 (Voltage or Current)

• Output ranges:

  • Voltage: 10 V

  • Current: 020 mA

• Load impedance:

  • Voltage outputs: 1 k

  • Current outputs: 500

Analog Value Generation

• AI resolution: Max. 12 bit (Voltage: 11+sign bit, Current: 11 bit)

• AO resolution: Max. 11 bit (Voltage: 11+sign bit, Current: 11 bit)

• Interference suppression: 10 / 50 / 60 / 400 Hz

• Smoothing (parameterizable, 4 stages): 1x, 4x, 16x, 32x cycle time

Diagnostics / Status

• Diagnostics function: Yes

• Monitored conditions: Supply voltage, wire-break, short-circuit

• LED indicators: For input and output status

Degree of Protection

• IP rating: IP20

Dimensions

• Width Height Depth: 45 100 81 mm

• Weight: 173.4 g
