SIEMENS PLC Modules 6ES7322-1BH10-0AA0

The SIEMENS 6ES7322-1BH10-0AA0 PLC modules are robust components designed for industrial automation.

Key Specifications:

• Rated Voltage: 24V DC

• Rated Current: 110 mA

• Power Loss: 5 W

• Frequency: 5060 Hz

• Operating Temperature: -20C to +60C

• Humidity Tolerance: Up to 95%

• Dimensions (L W H): 40 125 120 mm

• Weight: 200 g

• Mounting: DIN rail

• Connection Type: 20-pin

• Isolation Voltage: 500 V DC

• Protection Level: IP20

• "651" data-end="666" >Features:

  • Compact and lightweight design for easy handling and installation

  • Reliable and energy-efficient performance

  • Durable construction for demanding industrial environments

  • Simplified integration into existing systems with 20-pin connection

  • Safe operation ensured by high isolation voltage

  These PLC modules provide precision, reliability, and efficiency for modern automation applications.

  Siemens SM 322 Digital Output Module High Speed

  Part No.: 6ES7322-1BH10-0AA0
  SIMATIC S7-300 | 16 DO | 24 V DC | 0.5 A | Isolated | High-Speed

  Supply Voltage

  • Load voltage (L+)

    • Rated value: 24 V DC

    • Permissible range: 20.4 28.8 V DC

  Input Current

  • From L+ (no load): max. 110 mA

  • From backplane bus (5 V DC): max. 70 mA

  Power Loss

  • Typical: 5 W

  Digital Outputs

  • Number of outputs: 16

  • Short-circuit protection: Yes (Electronic)

    • Trip threshold: typ. 1 A

  • Inductive shutdown voltage: L+ (53 V)

  • Digital input control support: Yes

  Switching Capacity

  • Lamp load: max. 5 W

  Load Resistance

  • 48 4 k

  Output Voltage

  • Signal 1: L+ 0.8 V

  Output Current

  • Rated: 0.5 A

  • Permissible range (040 C): 5 mA 0.6 A

  • Permissible range (4060 C): 5 mA 0.6 A

  • Minimum load: 5 mA

  • Residual current (signal 0): max. 0.5 mA

  Output Delay

  • 0 1: max. 100 s

  • 1 0: max. 200 s

  Parallel Switching

  • Uprating: No

  • Redundant control: Yes (within same group)

  Switching Frequency

  • Resistive load: max. 1000 Hz

  • Inductive load: max. 0.5 Hz

  • DC13 inductive (IEC 60947-5-1): max. 0.5 Hz

  • Lamp load: max. 10 Hz

  Total Current per Output Group

  • Horizontal installation:

    • Up to 40 C: max. 4 A

    • Up to 60 C: max. 3 A

  • Vertical installation:

    • Up to 40 C: max. 2 A

  Cable Length

  • Shielded: max. 1000 m

  • Unshielded: max. 600 m

  Diagnostics / Status

  • Alarms: No

  • Diagnostics: No

  • Diagnostic alarms (wire-break, short-circuit, fuse, missing voltage): No

  • LEDs:

    • DO status (green): Yes, per channel

    • PWR, FSG: No

  Isolation

  • Between channels: Yes (group of 8)

  • Channels backplane: Yes (Optocoupler)

  • Isolation test: 500 V DC

  Connection

  • Required connector: 20-pin front connector

  Mechanical Data

  • Width: 40 mm

  • Height: 125 mm

  • Depth: 120 mm

  • Weight: approx. 200 g




  Specification	Details
  Product Name / Model	6ES7322-1BH10-0AA0
  Voltage	24 V DC
  Isolation	500 V DC
  Power loss	5 W
  Input current	110 mA
  IP protection	IP20
  Frequency	50 - 60 Hz
  Connection method	20-pin
  Net weight	200 g
  Dimensions	40 x 125 x 120 mm
