SIEMENS POWER SUPPLY 6EP4346-7RB00-0AX0

About SIEMENS POWER SUPPLY 6EP4346-7RB00-0AX0

The SIEMENS POWER SUPPLY 6EP4346-7RB00-0AX0 is a reliable and high-quality power supply designed for industrial use. With a voltage of 24 Volt, it ensures optimal performance in various industrial applications. The power mode is electric, providing efficient and consistent power delivery. The power supply comes in a sleek grey color, making it suitable for various industrial settings. It is in new condition, guaranteeing top-notch quality and performance. The standard size of this product ensures easy integration into existing systems. Backed by a 1-year warranty, you can trust in the durability and longevity of this power supply.

Siemens SITOP RED1200 Redundancy Module 24/48 V DC / 2x10 A

Part Number: 6EP4346-7RB00-0AX0

Function: Suitable for decoupling two SITOP power supplies with max. 10 A output each

Input

• Type: DC voltage

• Supply Voltage: 12 48 V DC

• Input Voltage Range: 10 58 V DC

Output

• Number of Outputs: 1

• Output Voltage: 24 V DC (Vin approx. 0.6 V)

• Output Voltage Adjustable: No

• Output Current (Rated): 20 A

• Bridging of Equipment: No

Efficiency & Power Loss

• Efficiency: 97.5 %

• Power Loss:

  • At rated load: 12 W (typical)

  • No-load: Max 0.1 W

Safety

• Galvanic Isolation: No

• Protection Class: IP20

• Operating Resource Protection Class: Class III

EMC Standards

• Emitted Interference: EN 61000-6-3

• Interference Immunity: EN 61000-6-2

Approvals & Certificates

• CE Marking: Yes

• UL Approval: Yes; cULus-Listed (UL 508, CSA C22.2 No. 107.1, File E197259)

• CSA Approval: Yes; CSA C22.2 No. 62368-1

• NEC Class 2: No

• MTBF at 40 C: 8,100,000 h

Hazardous Environments: Not certified for IECEx, ATEX, ULhazloc, cCSAus Class 1 Div 2, or FM

Marine Classification: No

Environmental Product Declaration: Yes

• Global Warming Potential:

  • Total: 396.8 kg CO2 eq

  • Manufacturing: 51.1 kg

  • Operation: 1051.5 kg

  • End of Life: 0.81 kg

Ambient Conditions

• Operating Temperature: -40 +70 C (natural convection)

• Transport / Storage: -40 +85 C

• Environmental Category (IEC 60721): 3K3, 595 % RH, no condensation

Connection Method

• Electrical Connection: Push-in terminals

  • Input (In1, In2): 0.2 10 mm

  • Output (Out1): 0.2 10 mm

Mechanical Data

• Dimensions (W H D): 35 135 125 mm

• Installation Width Mounting Height: 35 mm 225 mm

• Required Spacing: Top/Bottom 45 mm, Left/Right 0 mm

• Mounting Method: DIN Rail EN 60715 35x7.5/15

• Wall Mounting: No

• Housing Can Be Lined Up: Yes

• Net Weight: 0.47 kg
