SIEMENS POWER SUPPLY 6ES7288-0KD10-0AA0

About SIEMENS POWER SUPPLY 6ES7288-0KD10-0AA0

The Siemens Power Supply 6ES7288-0KD10-0AA0 is a reliable and efficient power source designed for industrial use. With a sleek black color and a standard size, this electric power supply operates at 240 volts and comes with a 1-year warranty. It is a new product in excellent condition, ideal for various industrial applications where a stable power source is essential.

SIMATIC PM207/1AC/24VDC/10A S7-200 Smart Power Supply

Article No.: 6ES7288-0KD10-0AA0
Type: Stabilized Power Supply, 24 V DC / 10 A

Input

• Power Supply Type: 1-phase AC

• Voltage Range (AC): 100 240 V

  • Min: 100 V

  • Max: 240 V

  • Initial: 85 V

  • Full-scale: 264 V

• Voltage Range (DC): 90 370 V

• Wide Range Input: Yes

• Line Frequency: 47 63 Hz

• Input Current:

  • 120 V AC: 2.31 A

  • 230 V AC: 1.14 A

• Inrush Current (25C): max. 30 A

• It Value: max. 1.5 As

• Fuse Protection: Internal, recommended 10 A, characteristic C

• Mains Buffering Time (rated output): min. 20 ms

Output

• Rated Output Voltage: 24 V DC

• Adjustable Output Voltage: 22.8 28 V (via potentiometer)

• Rated Output Current: 10 A

• Derating at 6070C: 2.5% / K

• Output Voltage Precision:

  • Slow input fluctuation: 0.1%

  • Slow load fluctuation: 0.5%

  • Fast input fluctuation 15%: 0.5%

  • Load step (10% 90%): 3%

• Voltage Peak: max. 50 mV (typical 25 mV)

• Overshoot at Switch-on: <1%

• Response Delay: max. 1.5 s

• Voltage Rise Time: typical 100 ms

• Supplied Active Power: 240 W

• Efficiency: 91%

• Power Loss: 24 W

Parallel Operation

• Bridging / Parallel Equipment: Yes, max. 2 units

Protection & Monitoring

• Short-Circuit Proof: Yes, constant current limiting

• Current Limitation: 11 12 A (typ. 12 A)

• Overvoltage Protection: <33 V

• Galvanic Isolation: Input Output: Yes, Safety Extra Low Output Voltage (EN 60950-1)

• Protection Class: Class I, IP20

• Leakage Current: max. 3.5 mA

EMC Compliance

• Emitted Interference: EN 55022 Class B

• Mains Harmonics Limitation: EN 61000-3-2

• Interference Immunity: EN 61000-6-2

Certifications & Approvals

• CE Marking: Yes

• UL / cULus: Yes (UL 508, CSA C22.2 No. 107.1)

• CCC Approval: Yes

• BIS Certificate: Yes, R-41184349

• CB-Certificate: Yes

• MTBF:

  • 40C: 500,000 h

  • 25C (MIL-HDBK-217F, full load, 220 V AC input): 500,000 h

Ambient Conditions

• Operation: -25C +70C (natural convection)

• Storage / Transport: -40C +85C

• Environmental Class: IEC 60721, 3K3, 595% RH, no condensation

Connection & Mechanical Data

• Electrical Connection: Screw terminal

  • Input (L, N, PE): 0.5 6 mm

  • Output (+1, +2, -1, -2): 0.5 6 mm

• Dimensions: 60 125 125 mm (W H D)

• Installation Footprint: 100 165 mm

• Required Spacing: Top/Bottom/Left/Right: 20 mm

• Mounting: DIN rail EN 60715 (357.5/15), wall mount possible

• Net Weight: 0.925 kg
