Siemens S7-1200 1215C CPU PLC

The Siemens S7-1200 1215C CPU PLC (Model: 6ES7215-1AG40-0XB0) is a powerful and compact programmable logic controller designed for diverse automation applications. Operating on a rated voltage of 24V DC, this PLC ensures efficient performance and reliability in industrial environments. It features a robust IP20 protection level and operates seamlessly in temperatures ranging from -20C to +60C. With dimensions of 130 x 100 x 75 mm and a lightweight design of just 500 grams, it is easily mounted on DIN rails for quick installation. The PLC supports an input voltage of 500 milliamperes and delivers an output of 1,600 mA, while its power rating stands at 12 watts, ensuring optimal energy efficiency. Built to withstand humidity levels up to 95%, the Siemens S7-1200 1215C CPU PLC is perfect for demanding conditions. Its sleek grey finish further enhances its professional aesthetic.

General Information

• Product: CPU 1215C DC/DC/DC

• Firmware: V4.7

• Programming Software: STEP 7 V20 or higher

Power Supply

• Rated Voltage: 24 V DC

• Range: 20.428.8 V DC

• Reverse Polarity Protection: Yes

• Load Voltage L+: 24 V DC (20.428.8 V DC)

Current Consumption

• CPU Only: 500 mA

• With Modules: 1500 mA

• Inrush Current: 12 A at 28.8 V

• Power Loss: 12 W (typ.)

Memory

• Work Memory: 200 KB

• Load Memory: 4 MB internal

• SIMATIC Memory Card: Supported

• Backup: Maintenance-free, without battery

CPU Performance

• Bit Operations: 0.08 s

• Word Operations: 1.7 s

• Floating Point: 2.3 s

Retentive Memory

• Retentive Area: 14 KB

• Flags: 8 KB

• Local Data: 16 KB (Priority 1), 6 KB (Others)

I/O Specifications

Digital Inputs (14 DI)

• Voltage: 24 V DC

• "0" Signal: 5 V

• "1" Signal: 15 V

• Input Delay: 0.120 ms (parameterizable)

• High-Speed Counting: 6 DI (up to 100 kHz)

• Cable Length: 500 m (shielded)

Digital Outputs (10 DO)

• Type: 24 V DC

• Max Current: 0.5 A per channel

• High-Speed Outputs: 4 PTO (100 kHz)

• Cable Length: 500 m (shielded)

Analog Inputs (2 AI)

• Range: 010 V

• Resolution: 10-bit

• Conversion Time: 625 s per channel

Analog Outputs (2 AO)

• Range: 020 mA

• Resolution: 10-bit

Communication Interfaces

PROFINET (2 Ports, RJ45)

• IO Controller & IO Device support

• Speed: 100 Mbit/s

• Media Redundancy (MRP): Yes

• Web Server: Yes

• Open IE Communication: TCP/IP, UDP, ISO-on-TCP

• OPC UA Server: Supported (license required)

Additional Protocols

• Modbus

• AS-Interface (via module)

• PROFIBUS (via CM module)

Diagnostics & Functions

• LEDs: RUN/STOP, ERROR, MAINT

• Traces: 2 (512 KB each)

• Forcing: Supported

• PID Control: Yes

• High-speed Counters: 6

• Pulse Outputs: 4 (100 kHz)

Mechanical & Environmental

• Protection: IP20

• Dimensions: 130 100 75 mm

• Weight: 500 g

• Operating Temperature: 20 to +60 C

• Storage Temperature: 40 to +70 C

• Humidity: 95% (no condensation)

• Vibration: 2 g (wall), 1 g (DIN rail)

Technical Details
