About Siemens S7-1200 CPU 1215C DC DC Relay

NAKSH TECHNOLOGY We have excellent range of Siemens PLC S7 1200which have an excellent designs and they provide a high quality of integration between the controllers and provide an effective performance to the clients. It offers very accurate and precise carrying out of the automation tasks.

Features

• Scalable and flexible designs
• Reasonable price
• Reliable
• Integrated Profinet System
• PID Functionality for close looped systems

Data Sheet 6ES7215-1HG40-0XB0

SIMATIC S7-1200 CPU 1215C (DC/DC/Relay)

General Information

• Product type: CPU 1215C DC/DC/relay

• Firmware version: V4.7

• Programming software: STEP 7 V20 or higher

Supply Voltage

• Rated: 24 V DC

• Permissible range: 20.4 28.8 V DC

• Reverse polarity protection: Yes

Load voltage L+: 24 V DC (20.4 28.8 V)

Current and Power

• CPU current consumption (typ.): 500 mA

• Max with all expansion modules: 1,500 mA

• Inrush current (max): 12 A at 28.8 V DC

• It: 0.8 As

• Backplane bus (5 V DC, max): 1,600 mA

• Power loss (typ.): 12 W

Memory

• Work memory: 200 KB (integrated)

• Load memory: 4 MB (integrated)

• SIMATIC Memory Card support: Yes

• Backup: Yes, maintenance-free, without battery

CPU Performance

• Bit operations: 0.08 s

• Word operations: 1.7 s

• Floating-point arithmetic: 2.3 s

CPU Blocks

• Max addressable blocks: 165,535

• OBs: Limited only by RAM

• Retentive data area: 14 KB

• Flags (bit memory): 8 KB

• Local data per priority class:

  • Priority 1: 16 KB

  • Priority 226: 6 KB

Address Area

• Process image inputs: 1 KB adjustable

• Process image outputs: 1 KB adjustable

Hardware Configuration

• Max modules per system: 3 communication modules, 1 signal board, 8 signal modules

Clock

• Real-time hardware clock: Yes

• Backup time: 480 h

• Deviation per day: 60 s/month at 25 C

Digital Inputs

• Number of inputs: 14 (6 for high-speed counting)

• Input voltage: 24 V DC

  • Signal 0: 5 V DC at 1 mA

  • Signal 1: 15 V DC at 2.5 mA

• Input delay: Parameterizable, min. 0.2 ms, max. 12.8 ms

• Technological functions: 3 @ 100 kHz single phase / 3 @ 30 kHz single phase / 3 @ 80 kHz differential / 3 @ 30 kHz differential

• Cable length: Shielded max. 500 m; Unshielded max. 300 m

Digital Outputs

• Number of outputs: 10 relay

• Switching capacity:

  • Resistive load: max. 2 A

  • Lamp load: 30 W DC / 200 W AC

• Output delay: max. 10 ms

• Relay operating cycles: 10 million mechanical, 100,000 at rated load

Analog Inputs

• Number: 2

• Input range: 010 V

• Input resistance: 100 k

• Cable length: Shielded max. 100 m

Analog Outputs

• Number: 2

• Output range: 020 mA

• Resolution: max. 10 bit

• Integration / Conversion time: 625 s

Encoders

• Connectable: 2-wire sensor

Interfaces

• Type: PROFINET

• Ports: 2 RJ45, integrated switch

• Features: Isolated, auto detection, autonegotiation, autocrossing

• Protocols: PROFINET IO Controller/Device, S7 communication, Open IE, Web server, OPC UA, MODBUS, PROFIBUS (with CM), AS-Interface (with CM)

OPC UA

• Server: Yes (Basic license required)

• Security: Anonymous or username/password; TLS 1.3 supported

• Max sessions: 10

• Max subscriptions per session: 5

S7 Communication

• Supported: Yes, client and server

• User data per job: See online help

Connections

• Overall max: 68

• Reserved: 34

Diagnostics

• LEDs: RUN/STOP, ERROR, MAINT

• Alarms, forcing, trace functions: Supported

• Counters: 6 (max. frequency 100 kHz)

• Positioning axes: Up to 8 controlled axes

Potential Separation

• Digital inputs: 500 V AC (1 min), per channel group

• Digital outputs (relays): No separation between groups of 2

EMC / Interference

• ESD: 8 kV air, 6 kV contact

• Cable-borne: IEC 61000-4-4

• Surge: IEC 61000-4-5

• High-frequency: IEC 61000-4-6

• Emission: EN 55011, Class A/B

Degree of Protection

• IP20

Standards & Approvals

• CE, UL, cULus, FM, RCM, KC, Marine

Environmental

• Environmental declaration: Type II ISO 14021

• Global warming potential:

  • Total: 106 kg CO

  • Production: 18.5 kg

  • Operation: 88.2 kg

  • End-of-life: 1.1 kg

Ambient Conditions

• Operating temperature: 20 to 60 C (horizontal), 20 to 50 C (vertical)

• Storage temperature: 40 to 70 C

• Humidity: max. 95% (no condensation)

• Vibration / Shock: IEC 60068-2-6 / 2-27 tested

• Altitude: 1,000 to 5,000 m

Programming

• Languages: LAD, FBD, SCL

• Protection: User program, copy, block, access levels (write, read/write, full)

• User administration: 42 users, 14 groups, 20 roles

• Cycle time monitoring: Adjustable

Dimensions & Weight

• Width: 130 mm

• Height: 100 mm

• Depth: 75 mm

• Weight: approx. 585 g
