Siemens S7-200 Smart 2di 2do Module

About Siemens S7-200 Smart 2di 2do Module

NAKSH TECHNOLOGY We are offering Siemens S7 200 Smart PLC MODULES to our client. SIMATIC S7-200 SMART PLC is designed to suit the needs of developing markets that have higher pressures of price and demands on performance. Providing an excellent performance-to-price ratio, SIMATIC S7-200 SMART PLC when combined with other SMART drive products from Siemens helps in building extremely cost effective efficient automation solutions.

Siemens S7-200 SMART SB DT04

Product Code: 6ES7288-5DT04-0AA0
Type: Digital I/O (2 DI / 2 DO)

Digital Inputs: 2 24 V DC
Digital Outputs: 2 24 V DC / 0.75 A

General Information:

• Product Type Designation: SB DT04, DI 224 V DC, DQ 224 V DC / 0.75 A

• Configuration in RUN (CiR): Not supported

• Reparameterization in RUN: No

Supply & Power:

• Rated Supply Voltage: 24 V DC (15 / +20 %)

• Permissible Range: 20.4 28.8 V DC

• Input Current (typical): 50 mA

• Power Loss (typical): 1 W

Digital Inputs:

• Number of Inputs: 2

• Input Voltage:

  • Type: DC

  • Signal 0 max: 5 V

  • Signal 1 min: 15 V

• Input Current:

  • Signal 0 max: 1 mA

  • Signal 1 typical: 2.5 mA

• Input Delay (at rated voltage):

  • 0 1 max: 20 s

  • 1 0 max: 20 s

• Cable Length:

  • Shielded max: 500 m

  • Unshielded max: 300 m

Digital Outputs:

• Number of Outputs: 2

• Short-Circuit Protection: No

• Output Voltage:

  • Signal 0 max: 0.1 V

  • Signal 1 max: 20 V

• Output Delay (resistive load):

  • 0 1 max: 2 s

  • 1 0 max: 10 s

Diagnostics & Status:

• Status LEDs for inputs and outputs: Yes

Physical & Environmental:

• IP Degree of Protection: IP20

• Dimensions (W H D): 35 52.2 16 mm

• Weight: 18.1 g
