Siemens S7-300 CPU 317-2 PNDP

About Siemens S7-300 CPU 317-2 PNDP

SIMATIC S7-300 CPU317F-2 PN/DP The SIMATIC S7-300 CPU317F-2 PN/DP is a central processing unit with 1.5 MB work memory.Key Features: - High-performance processing- 1.5 MB work memory- PROFINET interface- DP master/slave functionality Key Specifications: - CPU type: CPU317F-2- Work memory: 1.5 MB- Interface: PROFINET- Compatibility: S7-300 series

Siemens SIMATIC S7-300 CPU 317F-2 PN/DP

Part Number: 6ES7317-2FK14-0AB0

General Information:

• CPU Type: CPU 317F-2 PN/DP

• Firmware Version: V3.2

• HW Functional Status: 01

• Work Memory: 1.5 MB

• Programming Software: STEP 7 V5.5 or higher, Distributed Safety V5.4 SP4

• Isochronous Mode: Yes (via PROFIBUS DP or PROFINET interface)

Supply Voltage:

• Rated: 24 V DC

• Range: 20.4 28.8 V DC

• Recommended external protection: 2 A min.

• Mains buffering: 5 ms

Input Current:

• Rated: 750 mA

• No-load: 150 mA

• Inrush current: 4 A

Power Loss: 4.65 W

Memory:

• Work Memory: 1,536 kB (integrated, non-expandable)

• Load Memory: Plug-in MMC (max 8 MB)

• Backup: Yes, via MMC (maintenance-free, no battery required)

CPU Processing Times:

• Bit operations: 0.025 s

• Word operations: 0.03 s

• Fixed point arithmetic: 0.04 s

• Floating point arithmetic: 0.16 s

CPU Blocks:

• Max total blocks: 2,048 (DB, FC, FB)

• Max DB size: 64 kB

• Max FB/FC size: 64 kB

• OBs: Cyclic, interrupt, alarm, and isochronous OBs supported

Counters & Timers:

• S7 counters: 512

• IEC counters: Unlimited (RAM-limited)

• S7 timers: 512

• IEC timers: Unlimited (RAM-limited)

Data Areas & Retentivity:

• Retentive data area: 256 kB

• Flags: 4,096 bytes (retentive MB 04095)

• Data blocks: Adjustable retentivity

Address Areas:

• Inputs: 8,192 bytes

• Outputs: 8,192 bytes

• Process image adjustable: 8,192 bytes

Digital & Analog Channels:

• Digital Inputs/Outputs: 65,536 (central 1,024)

• Analog Inputs/Outputs: 4,096 (central 256)

Expansion Units: Max 3

Interfaces:

• RS 485: 1 (isolated, max 200 mA)

• PROFINET: 1 (isolated, 2-port switch, 10/100 Mbit/s)

• MPI: 12 Mbit/s

• PROFIBUS DP master/device supported

PROFINET IO Controller:

• Transmission rate: 100 Mbit/s

• Supports IRT, shared device, prioritized startup

• Max connectable IO devices: 128 (64 with IRT)

PROFINET IO Device:

• User data per controller: 1,440 bytes

• Max submodules: 64

Communication Protocols:

• S7 Communication (server & client)

• PG/OP communication

• Global data communication

• Open IE communication (TCP/IP, ISO on TCP, UDP)

• PROFIenergy, PROFIsafe

Test & Commissioning:

• Status/control variables: Yes

• Forcing: Yes

• Diagnostic buffer: 500 entries (100 powerfail-proof)

• Breakpoints: 4

Ambient Conditions:

• Operating temperature: 0 60 C

• Storage temperature: -25 70 C

Dimensions & Weight:

• Width: 40 mm

• Height: 125 mm

• Depth: 130 mm

• Weight: 340 g
