SIEMENS S7 400 6ES7417 4XT07 0AB0

The SIEMENS S7 400 6ES7417 4XT07 0AB0 is a high-quality industrial automation system designed for robust and reliable performance in various applications. With a standard size and sleek grey color, this rack-mount system operates at a frequency of 50/60 Hertz (Hz). It comes with a 1-year warranty, providing peace of mind to users. Whether you are an exporter, manufacturer, supplier, or trader, this product caters to your industrial automation needs with efficiency and dependability.

Siemens SIMATIC S7-400 CPU 417-4

Part Number: 6ES7417-4XT07-0AB0

General Information:

• CPU Type: CPU 417-4

• Firmware Version: V7.0

• HW Functional Status: 01

• Isochronous Mode: Yes (PROFIBUS only)

• Programming Package: STEP 7 V5.4 or higher with HSP 261

Memory:

• Work Memory: 32 MB (16 MB code / 16 MB data)

• Load Memory: Expandable with FEPROM (up to 64 MB) and RAM (up to 64 MB)

• Backup: Yes, with battery for all data

• Backup Current: Typ. 225 A, Max. 1 275 A

CPU Processing Times:

• Bit operations: 7.5 ns

• Word operations: 7.5 ns

• Fixed-point arithmetic: 7.5 ns

• Floating-point arithmetic: 15 ns

CPU Blocks:

• DB: Max 16,000 (64 kB each)

• FB: Max 8,000 (64 kB each)

• FC: Max 8,000 (64 kB each)

• OB: Max as per instruction list; includes cyclic, error, alarm OBs

Timers and Counters:

• S7 Counters: 2,048 (adjustable retentivity)

• S7 Timers: 2,048 (adjustable retentivity)

• IEC Counters/Timers: Unlimited (RAM limited)

Data Areas:

• Retentive Data Area: Total working and load memory (with backup battery)

• Flag Memory: 16 kB, retentive

• Local Data: Adjustable up to 64 kB

I/O Address Area:

• Inputs: 16 kB

• Outputs: 16 kB

• Process Image: Inputs 16 kB / Outputs 16 kB

• Subprocess Images: Max 15

Digital / Analog Channels:

• Digital Inputs: 131,072

• Digital Outputs: 131,072

• Analog Inputs: 8,192

• Analog Outputs: 8,192

Hardware Configuration:

• Max Expansion Units: 21

• Connectable OPs: 119

• Multicomputing: Up to 4 CPUs

• Connectable IMs: 6 total (IM 460s: 6, IM 463s: 4)

• DP Masters: Integrated 2, via CP or IM as per configuration

Interfaces:

• MPI/PROFIBUS DP, PROFIBUS DP, Plug-in IF Modules

• RS-485: 2 (MPI/PROFIBUS combined)

• PROFIBUS DP master: Max 32 connections, 12 Mbit/s

• Services: PG/OP communication, Routing, S7 communication (client/server), Direct data exchange, Isochronous mode

Time Functions:

• Hardware Clock: Yes, retentive & synchronizable

• Deviation: Buffered max. 1.7 s/day, Unbuffered max. 8.6 s/day

• Operating Hours Counter: 16 counters, retentive

Programming:

• Languages: LAD, FBD, STL, SCL, CFC, GRAPH, HiGraph

• Access: User program protection, password, block encryption

Dimensions & Weight:

• Width: 50 mm

• Height: 290 mm

• Depth: 219 mm

• Weight: Approx. 900 g
