Siemens Sinamics G120 Drive 6SL3210-1PE21-8UL0

About Siemens Sinamics G120 Drive 6SL3210-1PE21-8UL0

The Siemens Sinamics G120 Drive 6SL3210-1PE21-8UL0 is a versatile V/F control drive designed for industrial applications. With a protection level of IP20, this drive ensures reliable operation in various industrial environments. It operates at a frequency range of 47-63 Hertz and is suitable for use with a rated voltage of 380-480 Volt. The compact dimensions of 100 x 292 x 165 millimeters make it a space-efficient solution for motor control needs. Backed by a 1-year warranty, this drive offers durability and peace of mind for industrial operations.

Data Sheet SINAMICS Power Module PM240-2

Article No.: 6SL3210-1PE21-8UL0
(Technical data may change. Rating plate values may differ.)

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 480 V 10%

• Line frequency: 47 63 Hz

• Rated current (LO): 22.20 A

• Rated current (HO): 19.80 A

Output

• Phases: 3 AC

• Rated voltage: 400 V IEC / 480 V NEC

• Rated power (LO): 7.50 kW / 10 hp

• Rated power (HO): 5.50 kW / 7.50 hp

• Rated current (LO): 18.00 A

• Rated current (HO): 13.20 A

• Max. output current: 27.00 A

• Pulse frequency: 4 kHz

• Output frequency (vector control): 0 200 Hz

• Output frequency (V/f control): 0 550 Hz

Overload Capability

Low Overload (LO)

• 110% for 57 s (cycle 300 s)

• 150% for 3 s (cycle 300 s)

High Overload (HO)

• 150% for 57 s (cycle 300 s)

• 200% for 3 s (cycle 300 s)

General Technical Specifications

• Power factor : 0.85

• cos : 0.95

• Efficiency : 0.97

• Sound pressure level (1 m): 72 dB

• Power loss: 0.20 kW

• Integrated filter: None

Ambient Conditions

• Cooling: Internal air cooling

• Cooling air requirement: 0.009 m/s

• Installation altitude: Up to 1,000 m

• Operating temperature:

  • LO: -10 40 C

  • HO: -10 50 C

• Transport/storage: -25 55 C

• Max. humidity: 95% (no condensation)

Connections

Line Side

• Terminals: Plug-in screw terminals

• Conductor size: 1.5 6 mm (AWG 1610)

Motor Side

• Terminals: Plug-in screw terminals

• Conductor size: 1.5 6 mm (AWG 1610)

Motor Cable Length

• Shielded: 50 m

• Unshielded: 100 m

Mechanical Data

• Protection: IP20 / UL open type

• Frame size: FSB

• Weight: 3.00 kg

• Dimensions (W H D): 100 292 165 mm
