Siemens V20 Vfd 6SL3210-5BE21-5CV0

About Siemens V20 Vfd 6SL3210-5BE21-5CV0

Product: SINAMICS V20 380-480 V 3 AC

Article Number (Market Facing Number): 6SL3210-5BE21-5CV0

Product Description:
Rated power 1.5 kW with 150% overload for 60 sec. Integrated filter C3. I/O: 4 DI, 2 DO, 2 AI, 1 AQ. Fieldbus: USS / MODBUS RTU with built-in BOP. Protection: IP20 / UL open. Size: A 90x166x146 (WxHxD).

Product Family: SINAMICS V20 basic converters

Technical Specifications:

• Enclosure Type: IP20

• Control Method: V/F Control

• Communication Interface: Modbus

• Motor Power: 1.5 kW / 2.0 HP

• Net Weight: 1.10 kg

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 480 V (-15 % / +10 %)

• Line frequency: 47 63 Hz

Output

• Number of phases: 3 AC

• Rated voltage: 400 V IEC / 480 V NEC

• Rated power: 1.50 kW (LO) / 2.00 hp (LO)

• Rated power: 1.50 kW (HO) / 2.00 hp (HO)

• Rated current: 4.10 A (LO & HO & IN)

• Pulse frequency: 4 kHz

• Output frequency: 0 550 Hz

Overload Capability

• Low Overload (LO): 110 % rated output current for 60 s, cycle time 300 s

• High Overload (HO): 150 % rated output current for 60 s, cycle time 300 s

General Technical Specifications

• Power factor : 0.72

• Offset factor cos : 0.95

• Efficiency : 0.98

• Integrated filter class: Class A

Communication

• Protocols: USS, Modbus RTU

Inputs / Outputs

• Standard digital inputs: 4

• Digital outputs:

  • Relay changeover contact: 1

  • Transistor: 1

• Analog inputs: 2 (can also be used as digital inputs)

• Analog outputs: 1

Ambient Conditions

• Cooling: External fan

• Installation altitude: 1,000 m (3,281 ft)

• Ambient temperature:

  • Operation: -10 60 C (14 140 F)

  • Storage: -40 70 C (-40 158 F)

• Relative humidity (max operation): 95 %

Connections

• Maximum motor cable length:

  • Shielded: 10 m (32.8 ft)

  • Unshielded: 50 m (164 ft)

Mechanical Data

• Mounting position: Wall mounting / Side-by-side mounting

• Degree of protection: IP20 / UL open type

• Frame size: FSA

• Net weight: 1.10 kg (2.43 lb)

• Dimensions (W H D): 90 166 145.5 mm (3.54 6.54 5.73 in)
