About SIEMENS VFD G120X 6SL3220-2YE26-0AF0

Enclosure Type IP20 Motor Power 11kW SINAMICS G120X Rated power: 11 kW At 110% 60s, 100% 240 s Radio interference suppression filter for category C2 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 Degree C Size: FSC Degree of protection IP20 / UL open type painting 3C2 with Basic Operator Panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP

SINAMICS G120X Power Module

Article No.: 6SL3220-2YE26-0AF0

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 480 V (+10% / -20%)

• Line frequency: 47 63 Hz

• Rated voltage: 400V IEC / 480V NEC

• Rated current (LO): 24.50 A / 21.30 A

• Rated current (HO): 18.25 A / 14.00 A

Output

• Phases: 3 AC

• Rated voltage: 400V IEC / 480V NEC

• Rated power (LO): 11 kW / 15 hp

• Rated power (HO): 7.5 kW / 10 hp

• Rated current (LO): 26 A / 21 A

• Rated current (HO): 18 A / 14 A

• Rated current (IN): 27 A

• Max. output current: 35 A

• Pulse frequency: 4 kHz

• Output frequency (vector): 0 200 Hz

• Output frequency (V/f): 0 550 Hz

Overload Capability

• LO: 110% of IL for 60 s in a 300 s cycle

• HO: 150% of IH for 60 s in a 600 s cycle

General Technical Data

• Power factor (): 0.70 0.85

• Cos : 0.96

• Efficiency: 0.98

• Sound pressure level: 67 dB

• Power loss: 0.344 kW

• Filter class: RFI Category C2 (integrated)

• EMC category: C2

• STO (Safe Torque Off): Supported (without SIRIUS, via S7-1500F)

Communication

• PROFINET, Ether Net/IP

Inputs / Outputs

Digital Inputs (Standard)

• Number: 6

• Switching levels:

  • 0 1: 11 V

  • 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe DI

• Number: 1

Digital Outputs

• Relay changeover contacts: 2

• Load: DC 30 V, 5 A

• Transistor outputs: 0

Analog / Digital Inputs

• Number: 2 differential

• Resolution: 10-bit

• Digital switching threshold:

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Outputs

• Number: 1 (non-isolated)

Motor Temperature Interface

• Sensor: PTC, KTY, Thermo-Click

• Accuracy: 5C

Closed-Loop Control

• V/f (linear / square-law / parameterizable): Yes

• V/f with FCC: Yes

• V/f ECO: Yes

• Sensorless vector control: Yes

• Vector control with sensor: No

• Encoderless torque control: No

• Torque control with encoder: No

Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3)

• Cooling: Air cooling (integrated fan)

• Cooling air: 0.018 m/s

• Altitude: 1000 m

• Operating temperature: 20 45C

• Storage: 25 55C

• Transport: 40 70C

• Max humidity: 95% (no condensation/icing)

Connections

Signal Cable

• 0.15 1.50 mm (AWG 24 16)

Line Side

• Screw terminals

• 1.50 16.00 mm (AWG 16 6)

Motor Side

• Screw terminals

• 1.50 16.00 mm (AWG 16 6)

Others

• PE: M4 screw

• Max motor cable: 150 m (shielded)

Mechanical Data

• Protection: IP20 / UL open type

• Frame size: FSC

• Weight: 7.66 kg

• Dimensions:

  • Width: 140 mm

  • Height: 295 mm

  • Depth: 218 mm

Standards / Compliance

• UL, cUL, CE, RCM, EAC, KCC, SEMI F47, REACH

• CE marking per EMC 2004/108/EC, LVD 2006/95/EC

Efficiency to IEC 61800-9-2

• Efficiency class: IE2

• Comparison values (90% / 100%): 36.8%

Operator Panel BOP-2

Screen

• LCD, monochrome

Mechanical

• Protection: IP55 / UL Type 12

• Weight: 0.140 kg

• Dimensions:

  • 70 106.85 19.6 mm

Ambient

• Operation: 0 50C

• Storage/Transport: 40 70C

• Humidity: 95%
