About SIEMENS VFD G120X 6SL3220-2YE36-0AF0

SINAMICS G120X Rated power: 37 kW At 110% 60s, 100% 240 s Radio interference suppression filter for category C2 380-480 V 3 AC +10/-20% 47-63 Hz Ambient temperature -20 to +45 Degree C Size: FSD Degree of protection IP20 / UL open type painting 3C2 with Basic Operator Panel Without IO expansion Fieldbus integrated: PROFINET PN, Ethernet IP

Data Sheet SINAMICS G120X

Article No.: 6SL3220-2YE36-0AF0

Rated Data

Input

• Number of phases: 3 AC

• Line voltage: 380 480 V (+10% / -20%)

• Line frequency: 47 63 Hz

• Rated voltage: 400 V IEC / 480 V NEC

• Rated current (LO): 70.00 A / 61.00 A

• Rated current (HO): 62.00 A / 54.00 A

Output

• Number of phases: 3 AC

• Rated voltage: 400 V IEC / 480 V NEC

• Rated power (LO): 37.00 kW / 50 hp

• Rated power (HO): 30.00 kW / 40 hp

• Rated current (LO): 75.00 A / 65.00 A

• Rated current (HO): 60.00 A / 52.00 A

• Rated current (IN): 77.00 A

• Max. output current: 102.00 A

• Pulse frequency: 4 kHz

• Output frequency (vector control): 0 200 Hz

• Output frequency (V/f control): 0 550 Hz

Overload Capability

• Low Overload (LO): 110% IL for 60 s / 300 s

• High Overload (HO): 150% IH for 60 s / 600 s

General Technical Specifications

• Power factor (): 0.90 0.95

• Offset factor (cos ): 0.99

• Efficiency (): 0.97

• Sound pressure level (1 m): 70 dB

• Power loss: 1.110 kW

• Filter class (integrated): Category C2 (RFI suppression)

• EMC category (with accessories): C2

• Safety function: Safe Torque Off (STO) without SIRIUS device

• Communication: PROFINET, EtherNet/IP

Inputs / Outputs

Standard Digital Inputs

• Number: 6

• Switching level 0 1: 11 V

• Switching level 1 0: 5 V

• Max. inrush current: 15 mA

Fail-safe Digital Inputs

• Number: 1

Digital Outputs

• Relay contacts: 2

• Load capacity: 30 V DC, 5 A

• Transistor outputs: None

Analog / Digital Inputs

• Number: 2 (Differential)

• Resolution: 10-bit

• Digital switching threshold:

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Output

• Number: 1 (Non-isolated)

PTC / KTY Interface

• Supports PTC, KTY, Thermo-Click

• Accuracy: 5C

Control Techniques

• V/f linear / square-law / parameterizable

• V/f ECO (linear / square-law)

• V/f with FCC

• Sensorless vector control

• No encoder-based control

Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling with integrated fan

• Cooling air requirement: 0.055 m/s

• Installation altitude: 1,000 m

• Temperature:

  • Operation: 20 45C

  • Transport: 40 70C

  • Storage: 25 55C

• Humidity: Max. 95% at 40C (no condensation/icing)

Connections

Signal Cable

• Conductor size: 0.15 1.50 mm (AWG 24 16)

Line Side

• Screw terminals

• Conductor size: 10 35 mm (AWG 8 2)

Motor Side

• Screw terminals

• Conductor size: 10 35 mm (AWG 8 2)

DC Link (Braking Resistor)

• PE: Screw terminal

Max. Motor Cable Length

• Shielded: 150 m

Mechanical Data

• Degree of protection: IP20 / UL open type

• Frame size: FSD

• Net weight: 20 kg

• Dimensions:

  • Width: 200 mm

  • Height: 472 mm

  • Depth: 248 mm

Standards & Approvals

• Standards: UL, cUL, CE, RCM, EAC, KCC, SEMI F47, REACH

• CE compliance: EMC Directive 2004/108/EC, LVD 2006/95/EC

Efficiency (IEC 61800-9-2)

• Efficiency class: IE2

• Reference comparison: 44.8% converter losses

Operator Panel BOP-2

Display

• LCD (monochrome)

Mechanical

• IP55 / UL Type 12

• Weight: 0.140 kg

• Dimensions: 70 106.85 19.60 mm

Ambient

• Operation: 0 50C

• Storage/Transport: 40 70C

• Humidity: 95%
