SIEMENS VFD G120XA 6SL3220-3YD10-0CB0

The SIEMENS VFD G120XA 6SL3220-3YD10-0CB0 is a highly efficient and reliable Variable Frequency Drive designed for industrial automation applications. With a compact design measuring 73 x 232 x 209 mm and weighing only 3.4 kg, it ensures space efficiency and ease of installation via DIN rail mounting. It operates within a voltage range of 380-440V and offers a rated power of 0.75 kW, making it ideal for managing 3-phase AC systems. The device accommodates humidity levels up to 95% and operates within a temperature range of -20C to 60C, ensuring dependable performance in challenging environments. Featuring IP20 protection, it offers basic safeguarding against foreign objects. The aluminium body with a matt finish adds durability and a sleek appearance. The VFD has a maximum output current of 2.40 A and rated current of 2.20 A, supporting frequencies between 47-63 Hz. A 1-year warranty guarantees assurance and quality support for seamless operation.

Rated Data

Input

• Phases: 3 AC

• Line voltage: 380 ... 440 V (+10% / 20%)

• Line frequency: 47 ... 63 Hz

• Rated current (LO): 2.10 A

Output

• Phases: 3 AC

• Rated voltage: 400 V

• Rated power (LO): 0.75 kW

• Rated current 400V (IN): 2.20 A

• Rated current 380V (IN): 2.20 A

• Rated current (LO): 2.20 A

• Max. output current: 2.40 A

• Pulse frequency: 4 kHz

• Output frequency (vector control): 0 ... 240 Hz

• Output frequency (V/f): 0 ... 550 Hz

Overload Capability

• Low Overload (LO):
  110% of base load current (IL) for 60 s in a 600 s cycle

• Max output current for 60 s in 600 s cycle

General Technical Specifications

• Power factor : 0.75 ... 0.93

• cos : 0.99

• Efficiency: 0.96

• Sound level (1 m): 55 dB

• Power loss: 0.043 kW

• Integrated filter: RFI filter Category C3

• EMC category (with accessories): Category C3

• STO safety function available

Communication

• USS

• Modbus RTU

• BACnet MS/TP

Inputs / Outputs

Digital Inputs

• Standard inputs: 6

• Switching levels:

  • 0 1: 11 V

  • 1 0: 5 V

• Max inrush current: 15 mA

• Fail-safe inputs: 0

Digital Outputs

• Relay contacts: 4

• Output rating: DC 30 V, 1.0 A

• Transistor outputs: 0

Analog / Digital Inputs

• Number: 2 (differential)

• Resolution: 12 bit

• Switching threshold:

  • 0 1: 4 V

  • 1 0: 1.6 V

Analog Outputs

• Number: 2 (non-isolated)

Motor Temperature Interface

• Supports PTC, KTY, PT1000, Thermo-Click
• Accuracy: 5 C

Closed-loop Control Modes

• V/f linear / square-law / parameterizable: Yes

• V/f ECO: Yes

• V/f with FCC: Yes

• Sensorless vector control: Yes

• Encoderless torque control: Yes

• Vector control with sensor: No

• Torque control with encoder: No

Ambient Conditions

• Board coating: Class 3C2 (IEC 60721-3-3:2002)

• Cooling: Air cooling, integrated fan

• Cooling air: 0.005 m/s

• Altitude: Up to 1000 m

• Temperature:

  • Operation: 20 60 C

  • Storage/Transport: 40 70 C

• Max humidity: 95% (no condensation/icing)

Connections

Signal Cable

• Conductor size: 0.15 ... 1.50 mm

Line Side

• Screw terminals

• Conductor size: 1.50 ... 2.50 mm

Motor End

• Screw terminals

• Conductor size: 1.50 ... 2.50 mm

Others

• DC link (braking resistor)

• PE: M4 screw

• Max motor cable length (shielded): 50 m

Mechanical Data

• Protection: IP20 / UL open type

• Frame size: FSA

• Net weight: 3.4 kg

• Dimensions:

  • Width: 73 mm

  • Height: 232 mm

  • Depth: 209 mm
