SIEMENS SIMATIC Busadapter BA 2xLC-LD 6ES7193 6AG50 0AA0

The SIMATIC Busadapter BA 2xLC-LD 6ES7193 6AG50 0AA0 is a high-quality industrial automation device designed for standard size rack mount installation. Featuring a sleek grey color, this busadapter operates at a frequency of 50/60 Hertz (HZ), making it suitable for various automation applications.

Data Sheet 6ES7193-6AG50-0AA0

SIMATIC Bus Adapter BA 2x LC-LD

2x LC-LD ports, single-mode fiber-optic cable, up to 20 km

General Information

• Product type designation: BA 2x LC-LD

Interfaces

• Number of PROFINET interfaces: 1 (2 ports switch)

• Type: 2 LC-LD single-mode fiber-optic cable

• Supports PROFINET IO protocol

• Number of LC ports: 2

  • Wavelength: 1270 1380 nm

  • Corresponds to: 100BASE-LX

Cable Length

• Single-mode fiber-optic cable (9/125 m): 20 km

• For topology or IRT configuration: 10 km

• Minimum transmit power: -15 dB

• Minimum receiver sensitivity: -28 dB

Ambient Conditions

Ambient Temperature (Operation)

• Horizontal installation: -30 C to +60 C

• Vertical installation: -30 C to +50 C

Altitude

• Max. installation altitude: 5,000 m

• Restrictions above 2,000 m (refer to ET 200SP system manual)

Dimensions

• Width: 20 mm

• Height: 69.5 mm

• Depth: 59 mm

Weight

• Approx.: 40 g
