About Simatic S7 1200 PLC & Modules

NAKSH TECHNOLOGY Simatic S7 1200 PLC & Modules that proposed by us is the best choice for small size automation solutions along with extended communication options as well as integrated technology functions. Comes in failsafe and standard versions, it is well engineered and developed by ingenious technocrats and team using hi-tech components & parts with approved engineering and manufacturing technologies in adherence with industry norms. In addition, clients can buy Simatic S7 1200 PLC & Modules in various specifications at negotiable prices.

Data Sheet 6ES7241-1AH32-0XB0

SIMATIC S7-1200 Communication Module CM 1241

• Interface: RS232, 9-pin D-sub

• Supports Freeport

General Information

• Product type: CM 1241 RS 232

Supply Voltage

• Rated DC: 24 V (Range: 20.428.8 V)

• Max. current consumption: 200 mA

• Power loss: 1.1 W (typical)

Interfaces

• Bus type: RS 232C (V.24)

• Number of interfaces: 1

• Cable length (point-to-point): Max. 10 m

Integrated Protocol Drivers

• Freeport: Yes

• ASCII: Yes (library function)

• Modbus RTU Master: Yes

• Modbus RTU Device: Yes

Supported Protocols

Freeport

• Telegram length: Max. 1 kB

• Bits per character: 7 or 8

• Stop bits: 1 (standard), 2

• Parity: None (standard), Even, Odd, Mark, Space

3964(R)

• Telegram length: Max. 1 kB

• Bits per character: 7 or 8

• Stop bits: 1 (standard), 2

• Parity: None (standard), Even, Odd, Mark, Space

Modbus RTU Master

• Address area: 149,999

• Max. number of devices: 247 (per network segment max 32; repeaters required to expand)

Modbus RTU Device

• Address area: 149,999

Diagnostics

• Diagnostics function: Yes

• LED indication: Status of outputs

Protection & Standards

• IP degree of protection: IP20

• CE, CSA, UL, cULus, FM, RCM, KC, Marine approvals

Ambient Conditions

• Operating temperature: -20 C to 60 C (horizontal), -20 C to 50 C (vertical)

• Storage temperature: -40 C to 70 C

• Free fall: Max. 0.3 m, 5 times (in packaging)

• Air pressure: 7951,080 hPa (operation), 6601,080 hPa (storage/transport)

• Relative humidity: Max. 95 % (non-condensing)

• Permissible temperature change: 555 C, 3 C/min

Dimensions & Weight

• Width: 30 mm

• Height: 100 mm

• Depth: 75 mm

• Weight: 150 g
