SIMATIC S7-1200F, CPU 1215 FC, 6ES7215-1HF40-0XB0

About SIMATIC S7-1200F, CPU 1215 FC, 6ES7215-1HF40-0XB0

SIMATIC S7-1200F, CPU 1215 FC, compact CPU, DC/DC/relay, 2 PROFINET ports, onboard I/O: 14 DI 24 V DC; 10 DO relay 2 A, 2 AI 0-10 V DC, 2 AO 0-20 mA DC, power supply: DC 20.4-28.8 V DC program/data memory 250 KB.

SIMATIC S7-1200F CPU 1215FC (DC/DC/Relay)

Article No.: 6ES7215-1HF40-0XB0

General Information

• Compact CPU, DC/DC/Relay

• Onboard I/O: 14 DI 24 V DC, 10 DO relay 2 A, 2 AI 010 V DC, 2 AO 020 mA DC

• Power supply: DC 20.428.8 V

• Program/data memory: 250 KB / 4 MB load memory

• Firmware version: V4.7

• Programming: STEP 7 V20 or higher

Supply & Power

• Rated voltage: 24 V DC

• Permissible range: 20.428.8 V DC

• Reverse polarity protection: Yes

• Input current (CPU only): 500 mA

• Input current (with expansion modules): max. 1.5 A

• Inrush current max: 12 A at 28.8 V DC

• Power loss: Typ. 12 W

Memory & Processing

• Work memory: 250 KB

• Load memory: 4 MB

• Backup: Yes, maintenance-free, without battery

• CPU processing times:

  • Bit operations: 0.08 s

  • Word operations: 1.7 s

  • Floating point: 2.3 s

Digital Inputs

• Number: 14 (6 usable for high-speed counting)

• Type: Source/sink input

• Rated voltage: 24 V DC

• Input delay (parameterizable): 0.120 ms

• Cable length: Shielded max 500 m; unshielded max 300 m

Digital Outputs

• Number: 10 (relay)

• Max load: 2 A resistive, 30 W DC lamp, 200 W AC lamp

• Output delay: max. 10 ms

• Cable length: Shielded max 500 m; unshielded max 150 m

Analog Inputs / Outputs

Analog Inputs:

• Number: 2

• Voltage range: 010 V

• Input resistance: 100 k

• Cable length: max 100 m (shielded)

Analog Outputs:

• Number: 2

• Current range: 020 mA

• Resolution: 10 bit

• Conversion time: 625 s

Encoders

• Connectable: 2-wire sensors

Communication Interfaces

• PROFINET IO Controller / Device

• Ports: 2 RJ45 with integrated switch

• Max transmission rate: 100 Mbit/s

• OPC UA Server support (runtime license required)

• PROFIBUS, MODBUS, AS-Interface supported via communication modules

• Web server support

• Media redundancy: MRP supported

Integrated Functions

• Counters: 6 (max. 100 kHz)

• Frequency measurement, positioning, PID control

• Alarm inputs: 4

Potential Separation & EMC

• Digital inputs: 500 V AC

• Relay outputs: Grouped separation

• Interference immunity: IEC 61000 series

• Emission: EN 55011, Class A/B

Ambient Conditions

• Operating temperature: 055 C (horizontal), 045 C (vertical)

• Storage temperature: -4070 C

• Relative humidity: max 95%, non-condensing

• Altitude: -1000 m to 5000 m

• Shock & vibration tested: IEC 60068-2-6 / IEC 60068-2-27

Safety & Certifications

• Safety: PLe (ISO 13849-1), SIL 3 (IEC 61508)

• CE, UL, cULus, FM, RCM, KC, Marine approvals

• Environmental product declaration: Yes

• Global warming potential: 106 kg CO eq

Mechanical Data

• Dimensions: W 130 mm H 100 mm D 75 mm

• Weight: 585 g

• Degree of protection: IP20
