The SIMATIC S7 1500 Digital Output Module, DQ 64, is designed for industrial automation applications. With a frequency range of 50/60 Hertz (Hz), this module features a rack-mountable design in a standard size. The output type is digital with a sleek black color and a color-coated surface finish, making it a versatile and reliable solution for various automation needs.

General information

• Product type designation: DQ 64x24VDC/0.3A BA

• HW functional status: from FS01

• Firmware version: V1.0.0

• FW update possible: Yes

Product function

• I&M data: Yes (I&M0 to I&M3)

• Isochronous mode: No

• Prioritized startup: No

Engineering with

• STEP 7 TIA Portal: V16 with HSP 0319 / V17

• STEP 7: V5.5 SP3

• PROFIBUS GSD: V1.0 / Rev. V5.1

• PROFINET GSD: V2.35

Operating mode

• DQ: Yes

• DQ with energy-saving: No

• PWM: No

• Cam control: No

• Oversampling: No

• MSO: Yes

• Integrated operating cycle counter: No

Supply voltage

• Rated value (DC): 24 V

• Range: 19.228.8 V

• Reverse polarity protection: Yes (7 A per group)

• External protection (recommendation): 24 V DC / 6 A MCB type B

Input current

• Max. current consumption: 90 mA (without load)

Output voltage / header

• Rated value: 24 V DC

Power

• From backplane bus: 0.6 W

• Power loss (typ.): 3.5 W

Digital outputs

• Type: Transistor

• Number of outputs: 64

• Current-sourcing: Yes

• Short-circuit protection: Yes

• Inductive shutdown voltage: L+ (53 V)

• Controls a digital input: Yes

Switching capacity

• Resistive load: 0.3 A max.

• Lamp load: 5 W max.

Load resistance

• Minimum: 80

• Maximum: 10 k

Output voltage

• Signal 1 (min.): L+ (0.8 V)

Output current

• Signal 1 rated: 0.3 A

• Signal 0 residual: max. 0.5 mA

Output delay

• 0 1: max. 100 s

• 1 0: max. 500 s

Parallel switching

• Logic links: Yes

• Uprating: No

• Redundant load control: Yes

Switching frequency

• Resistive load: 100 Hz max.

• Inductive load: 0.5 Hz max. (IEC 60947-5-1 DC-13)

• Lamp load: 10 Hz max.

Total current (module)

• Per channel: max. 0.3 A

• Per group: max. 2 A

• Per module: max. 8 A

• Horizontal installation (60 C): 8 A

• Vertical installation (40 C): 8 A

Cable length

• Shielded: 1000 m

• Unshielded: 600 m

Diagnostics / Status

• Diagnostics function: No

• Substitute values: No

• Diagnostic alarm: No

• Maintenance interrupt: No

• Supply monitoring: No

• Wire-break: No

• Short-circuit: No

• Group error: No

LEDs

• RUN: Yes (green)

• ERROR: Yes (red)

• MAINT: No

• PWR LED: Yes (via SIMATIC TOP connect)

• Channel status: via SIMATIC TOP connect

• Channel diagnostics: No

• Module diagnostics: No

Potential separation

• Between channels: No

• Groups of 16 (32 with TOP connect): Yes

• Between channels and backplane bus: Yes

• Isolation test: 707 V DC

Standards & approvals

• Siemens Eco Profile: Siemens EcoTech

• Suitable for safety functions: No

• Safety-related tripping of standard modules: Yes (from FS01)

Safety levels

• PL d (ISO 13849-1)

• Category 3

• SIL2 (IEC 62061)

Ambient conditions

• Operating temperature:

  • Horizontal: 30 to +60 C

  • Vertical: 30 to +40 C

• Altitude: up to 5000 m

Dimensions

• Width: 35 mm

• Height: 147 mm

• Depth: 129 mm

Weight

• Approx. 270 g
