About SIMATIC S7-1500F, 6ES7517-3FQ10-0AB0

The SIMATIC S7-1500F, 6ES7517-3FQ10-0AB0 is a cutting-edge automation solution specifically designed for industrial applications. This device comes with a service period of 12 months, ensuring long-term reliability and performance. Its elegant grey color and polished surface treatment give it a professional look. With dimensions of 175 x 147 x 129 millimeters and a weight of 1.499 grame, it is compact yet robust. The rack mount design allows for easy installation in various setups. Ideal for exporters, manufacturers, suppliers, and traders looking to streamline their automation processes.

Data Sheet 6ES7517-3FQ10-0AB0

SIMATIC S7-1500F, CPU 1517F-3 PN

• Central processing unit with 6 MB work memory for program and 50 MB for data

• Interfaces:

  • 1st: PROFINET IRT, 2-port switch

  • 2nd: PROFINET IRT, 2-port switch

  • 3rd: Ethernet

• Bit performance: 0.6 ns

• SIMATIC Memory Card required

General Information

• Product type: CPU 1517F-3 PN

• HW functional status: FS01

• Firmware version: V4.0 (FW update possible)

• Product functions:

  • I&M data: Yes, I&M0 to I&M3

  • Isochronous mode: Yes, Distributed and Central

  • SysLog: Yes

• Engineering: STEP 7 TIA Portal V20 (FW V4.0)

• Configuration via dataset: Yes

Display & Control

• Screen diagonal: 6.1 cm

• Keys: 8

• Mode buttons: 2

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 19.2 28.8 V DC

• Reverse polarity protection: Yes

• Mains buffering: 5 ms

Current & Power

• Rated current: 1.07 A, max: 1.5 A

• Inrush current max: 1.5 A, It: 0.4 As

• Power consumption from backplane: 30 W

• Power loss: typ. 13.6 W

Memory

• SIMATIC memory card slots: 1 (required)

• Integrated work memory: 6 MB program, 50 MB data

• Load memory: max 32 GB

• CPU processing times:

  • Bit operations: 0.6 ns

  • Word operations: 1.3 ns

  • Fixed-point: 1.3 ns

  • Floating-point: 3.8 ns

CPU Blocks

• Total elements: 20,000 (OB, FB, FC, DB, UDTs)

• DB number range: 160,999 (user: 159,999)

• Max sizes:

  • DB: 16 MB (64 KB for absolute addressing)

  • FB: 1 MB

  • FC: 1 MB

  • OB: 1 MB

• Free cycle OBs: 100

• Various specialized OBs: 100 startup, 20 time alarm, 50 process alarm, 3 isochronous mode, etc.

Counters & Timers

• S7 counters: 2,048 (retentive adjustable)

• IEC counters: Any (limited by memory)

• S7 timers: 2,048

• IEC timers: Any (limited by memory)

Data Areas

• Retentive data area: max 2.25 MB

• Extended retentive area: max 50 MB

• Flags: 16 KB, clock memories: 8

• Local data: 64 KB per priority class, 16 KB per block

Address Area

• IO modules: 16,384 max

• IO address area:

  • Inputs: 32 KB

  • Outputs: 32 KB

• Subprocess images: max 32

Hardware Configuration

• Distributed IO systems: 64 max

• DP masters via CM: 8 max

• Integrated IO Controllers: 2 max

• Rack modules: 32 max (CPU + 31 modules)

Time of Day

• Hardware clock backup: 6 weeks

• Deviation per day: max 10 s

• Operating hours counter: 16

• Clock synchronization: DP, AS, Ethernet via NTP

Interfaces

• PROFINET: 3 interfaces, 2-port switches (X1, X2), X3: 1 port
• Ethernet speeds: 100 Mbps / 1000 Mbps (X3 only)
• Protocols: IPv4, PROFINET IO Controller/Device, SIMATIC, Open IE, Web server, PROFIsafe, MODBUS TCP
• Connections: max 320, 288 via CPU interfaces, 64 S7 routing paths
• Media redundancy: MRP / MRPD supported

OPC UA

• Runtime license required: Yes ("Large")

• OPC UA Client & Server supported

• Max connections: 40

• Max nodes: 50,000

• Max monitored items: 50,000

• Alarms & conditions: Yes

Supported Technology Objects

• Motion Control: Yes (resources available: 20,480)

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

• High-speed counter: Yes

Safety / Security

• Performance level: PLe

• SIL: SIL3

• PROFINET Security Class: 1

• Signed firmware update: Yes

• Secure Boot & safe data removal: Yes

Ambient Conditions

• Operation (horizontal): 0 60 C (Display max 50 C)

• Operation (vertical): 0 40 C (Display max 40 C)

• Storage: -40 70 C

• Installation altitude: max 5,000 m

Programming

• Languages: LAD, FBD, STL, SCL, CFC, GRAPH

• User program protection: Yes (password, copy, block protection)

• Access protection: up to 100 users, 100 groups, 50 roles

Dimensions & Weight

• Width: 175 mm

• Height: 147 mm

• Depth: 129 mm

• Weight: 1,499 g
