About SIEMENS SIMATIC S7-1500F 6ES7518-4FP00-0AB0

Manufacturer Series: S7-1500
Brand: SIEMENS
Mounting Type: Rack Mount
Net Weight: 2,079 grams
Packaging Dimension: 175 x 147 x 129 mm

SIMATIC S7-1500F, CPU 1518F-4 PN/DP central processing unit with:

• 9 MB work memory for program and 60 MB for data

• 1st Interface: PROFINET IRT with 2-port switch

• 2nd Interface: PROFINET RT

• 3rd Interface: PROFINET basic services

• 4th Interface: PROFIBUS

• 1 ns bit performance

SIMATIC S7-1500F CPU 1518F-4 PN/DP

Article No.: 6ES7518-4FP00-0AB0

Type: Central Processing Unit (Fail-Safe), 9 MB program memory, 60 MB data memory

General Information

• HW Functional Status: FS11

• Firmware Version: V3.1 (FW update possible)

• I&M Data: Yes (I&M0 to I&M3)

• Isochronous Mode: Distributed and Central

• SysLog: Yes

• Engineering: STEP 7 TIA Portal (V19 or higher)

• Display: 6.1 cm diagonal

• Control Elements: 6 keys + 1 mode selector

Power Supply

• Rated Voltage: 24 V DC

• Permissible Range: 19.228.8 V

• Reverse Polarity Protection: Yes

• Current Consumption: 1.55 A (typ.), 1.9 A (max)

• Power Loss: 24 W (typ.)

• Backplane Bus Power: 12 W

Memory

• Program Memory: 9 MB

• Data Memory: 60 MB

• SIMATIC Memory Card: Required, max. 32 GB

• Backup: Maintenance-free

CPU Performance

• Processing Times:

  • Bit operations: 1 ns

  • Word operations: 2 ns

  • Fixed-point arithmetic: 2 ns

  • Floating-point arithmetic: 6 ns

• Blocks (OB, FB, FC, DB, UDT): 20,000 elements

• Data Blocks (DB): User DBs 159,999; Size max. 16 MB

• Function Blocks (FB): 065,535; Size max. 1 MB

• Organization Blocks (OB): Size max. 1 MB

Counters & Timers

• S7 Counters: 2,048 (retentive adjustable)

• IEC Counters: Any (limited by main memory)

• S7 Timers: 2,048 (retentive adjustable)

• IEC Timers: Any (limited by main memory)

I/O & Address Area

• Max I/O Modules: 16,384

• Inputs/Outputs: 32 KB each

• Subprocess Images: Max. 32

• Distributed I/O Systems: Max. 64

• DP Masters: 1 integrated + 8 via CM

Clock & Synchronization

• Hardware Clock Backup: 6 weeks

• Deviation per day: Max. 10 s

• Clock Sync: Supported via DP, AS, Ethernet (NTP)

Interfaces

PROFINET

1. X1: 2-port switch, IRT, Isochronous mode, max 512 devices

2. X2: 1-port, no switch, RT mode, max 128 devices

3. X3: 1-port, only Ethernet communication

PROFIBUS

• X4: RS-485, DP Master, max. 125 devices

Other

• Ethernet: 100/1000 Mbps, auto-negotiation

• PROFIsafe V2.4 / V2.6

Industrial Communication

• SIMATIC Communication: PG/OP, S7 Routing, Data Record Routing

• Open IE Communication: TCP/IP, UDP, ISO-on-TCP, DHCP, DNS, SNMP, DCP, LLDP, Optional Encryption

• Web Server: HTTP/HTTPS, web API (max 200 sessions)

• OPC UA: Client/Server, up to 50,000 registerable nodes, security policies, alarms, method calls

Technology Objects

• Motion Control: Yes, up to 15,360 resources

• Positioning Axes: 140 (4 ms cycle), 192 (8 ms cycle)

• PID Controllers: PID_Compact, PID_3Step, PID_Temp

• High-Speed Counters: Yes

Safety

• Performance Level: PLe (ISO 13849-1)

• SIL: SIL3 (IEC 61508)

• Failure Probability (20 years, 100 hr repair):

  • Low demand PFDavg < 2.0E-5

  • High demand PFH < 1.0E-9

Environmental & Operating Conditions

• Operating Temp (Horizontal): 060 C (Display max 50 C)

• Operating Temp (Vertical): 040 C

• Storage Temp: -4070 C

• Altitude Max: 5,000 m

• Environmental Product Declaration: Yes

• Global Warming Potential: 570 kg CO2 eq

Programming & Protection

• Programming Languages: LAD, FBD, STL, SCL, CFC, GRAPH

• User Program Protection: Yes (password, copy, block protection)

• Access Protection: Read/Write, Failsafe, Complete, User administration

Dimensions & Weight

• Width Height Depth: 175 147 129 mm

• Weight: 2,079 g
