About SIMATIC S7-200 smart 6ES7288-0CD10-0AA0

The SIMATIC S7-200 smart 6ES7288-0CD10-0AA0 is a versatile industrial automation system designed for efficient operation in manufacturing settings. This product operates on a voltage range of 100-240 Volts, comes in a sleek grey color, and offers a standard size suitable for various industrial applications. With an electric power mode, this new device is reliable and ensures seamless performance. It comes with a 1-year warranty, making it a dependable choice for your industrial automation needs.

Data Sheet: 6ES7288-0CD10-0AA0

SIMATIC PM207 / 1AC / 24VDC / 3A

SIMATIC S7-200 Smart Regulated Power Supply
Input: 100240 V AC
Output: 24 V / 3 A DC

Input

Power Supply Network: 1-phase AC

Supply Voltage (AC):

• Minimum rated value: 100 V

• Maximum rated value: 240 V

• Initial value: 85 V

• Full-scale value: 264 V

Input Voltage (DC): 88 370 V
Wide Range Input: Yes

Buffering Time (Rated Output): Minimum 20 ms
Mains Buffering Condition: At Vin = 170 V

Line Frequency:

• Nominal: 50/60 Hz

• Range: 47 63 Hz

Input Current:

• At 120 V AC: 1.65 A

• At 230 V AC: 0.75 A

Inrush Current Limitation (25 C): Max 30 A
It Value: Max 1.5 As

Fuse Protection:

• Internal: Yes

• Recommended external: 10 A (characteristic C)

Output

Voltage Curve: Controlled, isolated DC
Rated Output Voltage: 24 V
Adjustable Output Voltage: 22.8 26.4 V (via potentiometer)

Control Precision:

• Input voltage fluctuation (slow): 0.1 %

• Ohmic load fluctuation (slow): 0.5 %

Voltage Ripple:

• Maximum: 50 mV

• Typical: 25 mV

Status Display: Green LED (24 V OK)
Switch-On Behavior: Voltage overshoot < 1 %
Response Delay: Max 0.5 s
Voltage Rise Time: Typical 50 ms

Output Current:

• Rated value: 3 A

• Range: 0 3 A

• Derating (5570 C): 3.5%/K

Typical Active Power: 72 W
Parallel Operation: Allowed up to 2 units

Efficiency: 89 %
Power Loss: Typical 9 W

Closed-Loop Control

• Control precision (rapid input change 15%): 0.2 %

• Control precision (load step 10/90/10%): 3 %

• Setting time (1090% or 9010%): 1 ms

Protection & Monitoring

• Overvoltage protection: < 28.8 V

• Short-circuit proof: Yes

• Short-circuit characteristic: Constant current

• Current limit: 3.6 4.4 A (typ. 4 A)

• Enduring short-circuit RMS current: 4 A

Safety

• Galvanic Isolation: Yes

• Output voltage: SELV (EN 60950-1)

• Protection Class: Class I

• Leakage Current: Max 3.5 mA

• IP Rating: IP20

EMC Standards

• Emitted interference: EN 55022 Class B

• Harmonics limitation: EN 61000-3-2

• Immunity: EN 61000-6-2

Approvals & Certifications

• CE: Yes

• UL / cULus: Yes (UL 508, CSA 107.1)

• CSA: Yes

• CCC: Yes

• BIS: Yes (R-41184349)

• CB Certificate: Yes

• UKCA / EAC / RCM: No

• NEC Class 2: No

MTBF:

• At 40 C: 500,000 h

• At 25 C (MIL-HDBK-217F): Full load, 220 V AC

Hazardous Area Approvals: None (No IECEx, ATEX, UL HazLoc, etc.)

Marine Approvals: None

Ambient Conditions

• Operating Temperature: -25 +70 C (natural convection)
• Transport / Storage: -40 +85 C
• Climate Class (IEC 60721): 3K3 (595% non-condensing)

Connections

Connection Type: Screw terminals

Input (L, N, PE):

• 0.5 6 mm (single-core)

• 0.5 4 mm (stranded)

Output (+1, +2, -1, -2):

• 0.5 4 mm

Mechanical Data

• Enclosure (W H D): 45 100 81 mm

• Installation size: 85 140 mm

• Required spacing: 20 mm (top/bottom/left/right)

• Mounting: DIN rail (EN 60715), wall mounting supported

• Net weight: 0.46 kg
