About SIMATIC S7-200 SMART 6ES7288-1CR60-0AA1

Data Sheet: SIMATIC S7-200 SMART CPU CR60s

Article No.: 6ES7288-1CR60-0AA1
Compact CPU AC/DC/Relay

• 36 DI (24V DC)

• 24 DO (Relay 2A)

• AC Power Supply: 85264 V AC, 4763 Hz

• Program/Data Memory: 20 KB

General Information

• Product type: CPU CR60s AC/DC/Relay

• Programming software: STEP 7 Micro/WIN SMART

• Mounting: DIN rail

Supply Voltage

• Rated value (AC): 230 V AC (L1, N)

• Supported ranges:

  • 120 V AC: 85132 V

  • 230 V AC: 170264 V

• Permissible range: 85 264 V AC

• Line frequency: 47 63 Hz

• Reverse polarity protection: No

Load Voltage (L)

• Rated value (DC): 24 V

• Range: 5 250 V DC

Input Current / Power

• Current consumption (rated): 100 mA @ 220 V AC

• Max. current consumption: 150 mA @ 220 V AC

• Inrush current: 16.3 A @ 264 V

• Power loss: Max. 10 W

Memory

• Memory type: DDR

• Flash: Yes

• RAM: Yes

• Memory card: Not supported

CPU Processing Times

• Bit operations: 150 ns

• Word operations: 1.2 s

• Floating point: 3.6 s

Clock

• Type: Software clock

• Hardware real-time clock: No

Digital Inputs (36 Inputs)

• Usable for technology functions: 4 HSC inputs

  • 4 100 kHz (single-phase)

  • 2 50 kHz (A/B phase)

• Input type: 24V DC (source/sink)

• Logic levels:

  • Signal 0: < 5 V

  • Signal 1: +15 +30 V

• Input current:

  • Signal 0: 1 mA

  • Signal 1: 4 mA

• Input delay (selectable): 0.2 s 12.8 s

• Cable length:

  • Shielded: 500 m (HSC: 50 m)

  • Unshielded: 300 m

Digital Outputs (24 Relay Outputs)

• Load capacity (resistive): 2 A

• Lamp load: 30 W DC / 200 W AC

• Switching delay (max):

  • 0 1: 10 ms

  • 1 0: 10 ms

• Switching frequency: 1 Hz (resistive)

• Relay endurance:

  • Mechanical: 10 million cycles

  • Electrical: 100,000 cycles

• Cable length:

  • Shielded: 500 m

  • Unshielded: 150 m

Interfaces

• Ethernet: 0

• RS485: 1 port (Isolated 500 V AC / 707 V DC)

• Connector type: 9-pin Sub-D

• Max baud rate: 187.5 kbps

• Protocol support:

  • PROFINET: No

  • PROFIBUS: No

  • TCP/IP: No

EMC Specifications

• Electrostatic discharge:

  • Air: 8 kV

  • Contact: 4 kV

• RF immunity (IEC 61000-4-3):

  • 10 V/m (801000 MHz)

  • 3 V/m (1.42 GHz)

• Burst:

  • Supply: 2 kV

  • Signal cables: 2 kV

• Surge:

  • Supply lines: 1 kV (sym.), 2 kV (asym.)

• Conducted RF immunity: 10 V (150 kHz to 80 MHz)

• Emission standard: EN 61000-6-4

• Intended for industrial environments

Protection & Approvals

• IP rating: IP20

• CE marking: Yes

Ambient Conditions

• Operating temperature: 0 55 C
  (Vertical installation max: 45 C)

• Storage / transport: 40 70 C

• Free fall: 0.5 m (in packaging)

• Air pressure: 660 1080 hPa

• Installation altitude: 1000 2000 m

• Humidity: 95% (no condensation)

Programming Languages

• LAD

• FBD

• STL

Mechanical Data

• Width: 175 mm

• Height: 100 mm

• Depth: 81 mm

• Weight: Approx. 605 g
