SIMATIC S7-300 6ES7153-1AA03-0XB0

About SIMATIC S7-300 6ES7153-1AA03-0XB0

The SIMATIC S7-300 6ES7153-1AA03-0XB0 is a high-quality industrial product designed for various applications. Its sleek grey color and standard size make it suitable for industrial settings. This brand new product comes with a 1-year warranty, ensuring reliable performance. Powered by electricity, this device offers efficient operation for optimal productivity.

General Information

• Product type: IM 153-1 DP ST

• Vendor ID: 801Dh

• Installation: Horizontal / vertical

Supply Voltage

• Rated value: 24 V DC

• Permissible range: 20.4 28.8 V DC

• External protection: Not necessary

• Mains buffering: 5 ms

Current & Power

• Max current consumption: 350 mA at 24 V DC

• Inrush current (typ.): 2.5 A

• It: 0.1 As

• Backplane bus voltage: 5 V DC

• Max backplane bus current: 1 A

• Typical power loss: 3 W

Address Area

• Input addressing: 128 byte

• Output addressing: 128 byte

Hardware Configuration

• Max modules per DP device interface: 8

Interfaces

• Transmission: RS 485

• Max transmission rate: 12 Mbit/s

• Automatic baud rate detection: Yes

• Interface output current max: 90 mA

• Connection type: 9-pin Sub-D socket

PROFIBUS DP

• Bus protocol: PROFIBUS DP (EN 50170)

• Node addresses: 1 to 125

• Services: SYNC, FREEZE, Direct slave-to-slave exchange (Sender)

• GSD file: SIEM801D.GSD / SI01801D.GSG

• Isolation voltage: 500 V

Protection & Environment

• IP degree of protection: IP20

• Operating temperature: 0 60 C horizontal, 0 40 C vertical

• Max installation altitude: 3,000 m above sea level

Configuration Software

• STEP 7 / COM PROFIBUS / non-Siemens tools via GSD file

Dimensions & Weight

• Width Height Depth: 40 125 117 mm

• Weight: approx. 360 g
